Automatic Screw Dispenser

Specifications

ADJUSTABLE SCREW FEEDER FOR SCREWS - DIAMETERS 1.0 ~ 5.0mm

The A358 screw feeder is the ultimate piece of multi-functional supply equipment for the production line. This unit offers an exchangeable screw-feeding rail which allows for quick and simple switching action for servicing screw sizes between 1.0mm and 5.0mm (other adjustable screw feeders typically cater for screws from 1.4mm - 5.0mm), making this a very flexible feeder.



This is the first screw feeder compatible with screw dimensions <= 1.0mm.





Operation:

This unit is easy and quick to use, with a top load facility for the loose screws and easy pick-up.

This unit also has a vibration facility and buzzer which can be switched on or off.

This unit is light weight and compact.





Model	A358
Power Source	AC 100 ~ 240v DC 15v Switching Adaptor
Applicable Screw Type/Sizes	From M1.0 to M5.0 (1.0mm, 1.2mm, 1.4mm, 1.7mm, 2.0mm, 2.3mm, 2.6mm, 3.0mm, 3.5mm, 4.0mm, 5.0mm)
Scooping Chamber Capacity	200 ~ 200 c.c
Applicable Screw Length	Up to 19mm (under screw head)





12 month warranty.
