Help CenterWire Stripping and Twisting Machine - DPF1000
Related Products
Specifications
1.Voltage:110/220/240V 50/60 Hz2.Size:260mm x 160mm x 138mm
3.Weight:6 kgs
4.Warranty:12 Months
5.Wire Range:0.8 ~ 5.2 mm
DPF1000 Wire Stripping and Twisting Machine:
DPF1000 - Wire stripping and twisting machine. Low cost, fast & accurate wire stripping & twisting upto 5.2mm outer diameter.
The DPF1000 Wire Stripping machine will strip many insulations including PVC, PTFE, Teflon, Rubber, for a wide range of wire sizes between 0.8 mm ~ 5.2 mm overall diameter (Approx wire gauge of between 4 ~ 20 AWG).
A precision hinged carbide blade is centrifugally operated to produce a precise stripping action. To strip a wire simply insert into the unit and withdraw.
Blade setting is locked into place with no chance of adjustment drift or conductor damage. On stranded wires the removal of the insulation slug leaves the strands neatly twisted for termination or soldering.
The DPF1000 is fully guarded for operator protection and includes an automatic motor cut-out if the Stripping Head Guard is inadvertently removed.
Simple Set-up and stripping operation:
Select a Wire Guide for the correct wire diameter (see wire guide selection chart below) Insert into Stripping Head and lock into place with Locking Screw. Loosen Blade Block Locking Screw and set blade to conductor thickness.
Set Strip Length Stop to required stripping length Insert wire into Stripping Head until it touches the length stop, pause momentarily then withdraw wire. If the blade contacts the conductor(s) or the insulation slug is not removed adjust blade in or out as required and repeat test strip.
All adjustments can be made in situ on the machine.
Wire Guide Selection:
WIRE GUIDE SELECTION | |||||
| Guide Number |
Diameter (mm) |
Guide Number |
Diameter (mm) |
Guide Number |
Diameter (mm) |
| 1 | 5.2 | 9 | 3.6 | 17 | 2.0 |
| 2 | 5.0 | 10 | 3.4 | 18 | 1.8 |
| 3 | 4.8 | 11 | 3.2 | 19 | 1.6 |
| 4 | 4.6 | 12 | 3.0 | 20 | 1.4 |
| 5 | 4.4 | 13 | 2.8 | 21 | 1.2 |
| 6 | 4.2 | 14 | 2.6 | 22 | 1.0 |
| 7 | 4.0 | 15 | 2.4 | 23 | 0.8 |
| 8 | 3.8 | 16 | 2.2 | ||
Specification:
| Place of Origin | Hampshire, United Kingdom |
| Brand Name | Series 4 Ltd. |
| Model Number | DPF1000 |
| Usage | Stripping |
| Stripping and Twisting Machine | up to 5.2mm outer diameter |
| Voltage | 110/220/240V 50/60 Hz |
| Size | 260mm x 160mm x 138mm |
| Weight | 6 kgs |
| Minimum Strip Length | 0.50mm |
| Maximum Strip Length | 30.0mm |
| Minimum Wire Diameter | 0.70mm O.D. |
| Maximum Wire Diameter | 5.1mm |
| Machine Warranty | 12 Months |
| Minimum Order Quantity | 1 Piece/Pieces |
| Port | Southampton |
| Packaging Details | Standard Packaging |
| Delivery Time | Ex-stock |
| Payment Terms | D/P,T/T,Credit card, PayPal |
| Supply Ability | 100 Piece/Pieces per Month |
