Plastic Package Machine

Plastic Package Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Plastic Cup
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Plastic Cup
Place of Origin Guangdong, China
Brand Name Donglong
Model Number RXC-660S
Voltage 380v 50hz
Power(W) 70kw
Dimension(L*W*H) 3400x1400x2100mm
Weight 6.5T
Certification CE
Warranty 1year
After-sales Service Provided Overseas third-party support available

Specifications

Plastic Package Machine
1.Intellectualized temperature control
2.PLC control
3.Forming Style:by Servo Motor

Plastic Package Machine



The line is formed of Cup Making Machine. Using the plastic-sheet heating to a certain temperature after pressing the heat-sheet, many kinds of cup products can be made by the Cup Making Machine, for example, the soft-drink cup, milk cup, jelly cup, ice-cream and disposable cup. .

Material: PP, PS, PVC & PET



Key Features:

  1. The machine is controlled by PLC, using the Touch-screen,
  2. Servo Motor used in the Sheet-feeding Device & Pulling Device.
  3. The advantage of manpower saved and low cost in production.
  4. High in Automatic Production level, fast speed, forming square area is large.

Main Technical Parameters:

Power Supply 3-phase  380V  50Hz
Rated Power  70kw
Range of Sheet  PP, PS, PVC, PET
Thickness  0.3-2.5mm
Width  500-650mm
Forming Area  650×400mm
Forming Depth  0-160mm
Speed  20-25cycle/min
Air Consumption  3M³/M(0.6-0.8Mpa)
Dimension  Forming Main Body 3400×1400×2100mm
  Electric Box 1300×450×1700mm
Weight  6.5T



Mould Structure:

Plastic Package Machine



Plastic Package Machine



Noted: RXC-660S is complete with JP-650B & JP-800A Plastic Sheet Extruding Machine, please visit our website www.anping.en.china.cn
