Full Automatic Plastic Cup Forming Machine
- 50 Set / Sets per Month
- Shantou Port
- T/T
- Food Box Thermoforming Machine Disposable Plastic Cup Making Machine
- Plastic Cup Thermoforming Making Machine Disposable Plastic Cups Plate Machine
- Plastic Cup Machine Plastic Thermoforming Manufacturing Machine Full Automatic Plastic Cup Thermoforming Machine
- Plastic Cup Thermoforming Machine Full automatic Plastic Cup Making Machine
- High Efficiency PP Plastic Cup Making Machine PET Food Box Thermoforming Machine
- High Speed Manufacture Plastic Coffee Cup Cover Thermoforming Machine
Product Details
Condition: | New | Product Type: | Plastic Cup | Place of Origin: | Guangdong, China |
Brand Name: | Donglong | Model Number: | RXC-650P-III | Voltage: | 380V, 50HZ |
Power(W): | 139W | Dimension(L*W*H): | 12500X3000X2770mm | Weight: | 10T |
Certification: | CE | Warranty: | one year |
Product Description
Specifications
Full Automatic Plastic Cup Forming Machine1.Intellectualized temperature control
2.PLC touch screen
Full Automatic Plastic Cup Forming Machine
This is a fully automatic plastic cup making machine integrate the Thermoforming part and Inverted cup stacking function.
The process of this machine is thermoform the plastic sheet to make cups then the cups through to the Inverted device into to the Stacker for Automatic Stacking, Counting and out of the machine tidily.
Application Area:
It is suitable for forming PP, PS, PVC & PET, it can be produced disposable cups.
Key Features:
- This machine is controlled by PLC and using Touch-screen.
- It is used the servo motor in Sheet-feeding Device and Pulling Device.
- As this machine is fully automatic so it could help the plastic product manufacturer save the human resource and decrease production cost.
- The fast speed of this machine is suitable for using in high level production line.
- This machine is low pollution and wide range use for the manufacturer.
Main Technical Parameters:
Power | 3-phase, 380V, 50HZ |
Sheet Width | 500-650mm |
Range of Sheet | 0.6-2.0mm |
Max Forming Area | 600X300mm |
Max Forming Depth | 120mm |
Speed | 20-28 cycle/min |
Air Pressure | 0.6-0.7Mpa |
Air Consumption | 3m³/min |
Water Consumption | 2T/hr |
Machine Dimension | 12500X3000X2770mm |
Machine Weight | About 10T |
Mould Structure:
