Specifications
Heavy Duty 4 Claw Nuts with 1.8mm thicnkess1.material:steel,,etc
2.size :m10 with zinc plated
3.thincness:1.7mm
Heavy Duty 4 Claw Nuts with 1.7mm thicnkess
| size | M10X1.7 |
| height | 12mm |
| height of prong | 8mm |
| diameter | 24mm |
| thickness | 1.7mm |
| weight | 8g |
| non standard | yes |
| packing | 15kg/carton,36cartons/pallets |
1.Material: Carbon steel, alloy steel. Stainless steel
2.Standard: DIN 557/DIN562/DIN798/JIS B1163
3.Grade: 4, 6, 8, 10 etc
4.Surface Finish: Zinc plated. Black, plain, hot dipped galvanized, etc
5.Size: From M6-M24
6.finish:black ,plain,zinc ,plain,etc
7.OEM accepted
petitive price and high quality
9.main market: Italy,England,Russia,Turkey,America,Canada,Brazil, Argentina,Peru,Ecuador,South Africa, Australia, New Zealand, Iran, etc
10. Application
Sometimes old T-Nuts become damaged with use or are lost when furniture is moved. Damaged or lost T-Nuts need to be replaced. T-Nuts provide the nut base into which the hanger bolt of a furniture leg may be screwed. The hanger bolt screws into the T-Nut and extends up into a cavity predrilled to sufficient width and depth to contain the screwed in hanger bolt.
11. Note about Size
The size of the hanger bolt determines what the size the T-Nut needs to be. These T-Nuts fit the Metric Size M8 Hanger Bolts. It is important to select the proper size T-Nuts for your hanger bolts.
12. Installing the T-Nut
Select the location for the T-Nut installation
If a cavity is already present for the screwed in hanger bolt, all that needs to be done is to tap the T-Nut into the proper location with the sleeve of the T-Nut extending into the already present cavity.
If no cavity is present for the sleeve of the T-Nut and the hanger bolt, a new cavity will need to be drilled at the proper location. After the cavity is drilled, then the T-Nut may be tapped into the installation site.
The furniture leg is then securely screwed into the T-Nut and the installation is complete
Photo:
-Packing:
1.packing:small box /bulking packing/roll packing+carton+pallets
Usually,48cartons /pallets
-Shipping
1.by express: DHL,FEDEX,UPS,TNT,ARAMEX,etc
2.by sea
3.by air
1.sample :free sample is ok
2.make your logo label
3.packing as your requirements
4.OEM can be accepted
petitive price and high quality
1.Question: what's you material, OEM is ok ?
Answer:we have carbon steel and stainless steel material , any material can make as your requirements .
OEM is accepted .if large qty there is no need mould fee .
2.Question: free sample is ok ?
Answer:sample for standard is free. sample fee is need for non-standard . but freight you need to pay for it .
of course , you can save the sample fee and freight if you place the order . special sample will send you to test. then after confirmed large prouction will start.
3.Question:How is your packing ?
Answer:usually about inner packing we have bulking packing(polybag packing) ,roll packing ,small box packing ,then put into the carton , last packed into the pallets .
4.Question: How is your quality.
Answer: we can offer you the realted material report or quality export as your requirement.
Sample can offer you to test. about the the quality we can promise you the quality after the goods selled six month .
if some wrong happens cause the goods quality ,we will offer you the best solution.
Any questions please send us the email or call me . Thanks and have a nice day!
