Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > T30 Manufacturing CNC Punching Machine Hydraulic Punch Press With FANUC Oip CNC Control

T30 Manufacturing CNC Punching Machine Hydraulic Punch Press With FANUC Oip CNC Control

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

CNC

Power Source:

Hydraulic

Contact Supplier Request Quote Chat Now

Yangzhou Baohuilai Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not CNC

Power Source Hydraulic

Place of Origin Jiangsu, China

Brand Name YL

Model Number T30

Voltage 380V

Power(W) 25kw

Dimension(L*W*H) 5050*2700*2010

Certification ISO

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

T30 manufacturing CNC punching machine hydraulic punch press with FANUC Oip CNC Control

T30 CNC turret punchig machine

The machine is of wide closure-type frame, which is solid, receiving tempering treatment. It has follwing features: streamline body with side pin-positioning, sleeve structure and thick turret, accurate positioning, good guiding, high accuracy adjustable worm and gear mechanism,German H+L hydraulic station with high performance and low energy-consumption, special Japanese FANUC Oip CNC Control, long ballscrew and guideway with high speed and auto-lubrication, universal pneumatic and electric parts, auto floating clamp and stainless worktable with steel ball and brush on it.

		T30
		T30
Nominal force	kN	300	300	300	300	300
Max. Machining Sheet (Repositioning)	mm	1250	1250	1250	1500	1500
Max. Machining Sheet (Repositioning)	mm	2500	4000	5000	4000	5000
Slide Stroke	mm	32	32	32	32	32
Max. Plate Thk	mm	6.35	6.35	6.35	6.35	6.35
Max. Punching Dia.	mm	Φ88.9	Φ88.9	Φ88.9	Φ88.9	Φ88.9
Die Qty.	pc	30	30	30	30	30
Punching Accuracy	mm	±0.10	±0.10	±0.10	±0.10	±0.10
Slide SPM	mm	600/*900	600/*900	600/*900	600/*900	600/*900
Slide SPM	mm	600/*900	600/*900	600/*900	600/*900	600/*900
Max. Speed	m/min	106	106	106	106	106
Frame		Straight	Straight	Straight	Straight	Straight
Frame		O-Type	O-Type	O-Type	O-Type	O-Type
Throat Depth	mm	1275	1275	1275	1525	1525
Control Axis	pc	4	4	4	4	4
Turret Speed	r/min	30	30	30	30	30
Max. Punching Dia. Of Rotary Station	mm	Φ88.9	Φ88.9	Φ88.9	Φ88.9	Φ88.9
Power	kw	25	25	25	25	25
Max. Weight	kg	156	156	210	210	235
Air Pressure	MPa	0.55	0.55	0.55	0.55	0.55
Outline Size (FB×LR×H)	mm	5050×2700×2010	5050×4200×2010	5050×5200×2010	5650×4200×2010	5650×5200×2010
Weight	t	19.5	20	20.5	21.5	22
