200/500 Plastic High Speed Mixer

200/500 Plastic High Speed Mixer thumbnail-1
200/500 Plastic High Speed Mixer photo-1
US$ 2,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Wanjin
Model Number:
SRL
Contact Supplier Request Quote Chat Now
Zhangjiagang City Wanjin Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Wanjin
Model Number SRL

SRL series high speed mixer
Feature
Cylinder body made of corrosion-resistant stainless steel .
Vane is made of high strength stainless steel .
Special designed cylinder body does self-cleaning well
The shaft is sealed up by special material sealing and oil-resistant & heat-resistant sealing .
Heating mixer has self-friction . Its heating type is electric or steam heating .
It's not easy for arch cover of cooling mixer to be out of shape .
Materials are well mixed by fast & slow rotation together .
Application
It is mainly used for feeding, mixing, coloring and drying of various resins, polyethylene, polypropylene and PVC, etc. It can dry and volatilize before shaping of engineering plastics such as ABS and polycarbonate, etc. It can be used for mixing phenol aldehyde too.
It combines heating mixing and cooling mixing. Materials after heating mixing go into cooling mixer for cooling automatically. It exhausts remaining gases to avoid agglomerates.

Main Technical Parameter

SRL-Z series

Model

SRL-Z50/100

SRL-Z100/200

SRL-Z200/500

SRL-Z300/600

SRL-Z500/1000

SRL-Z800/1600

Total capacity

(L)

50/100

100/200

200/500

300/600

500/1000

800/1600

Effective capacity

(L)

36/75

75/150

150/375

225/450

375/750

600/1200

Main Shaft Speed

(r/min)

625/1250/130

525/1050/100

475/950/80

475/950/80

430/860/60

370/740/50

Type of heating/cooling

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Motor Power

(kw)

7/11/5.5

14/22/7.5

30/42/11

40/55/11

55/75/15

60/90/18.5



SRL-W series

Model

SRL-W100/400

SRL-W200/800

SRL-W300/1000

SRL-W500/1600

SRL-W800/2500

SRL-W1000/3000

Total capacity

(L)

100/400

200/800

300/1000

500/1600

800/2500

1000/3000

Effective capacity

(L)

75/300

150/600

225/750

375/1200

600/1800

750/2200

Main Shaft Speed

(r/min)

525/1050/130

475/950/100

475/950/80

430/860/80

370/740/60

325/650/50

Type of heating/cooling

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Self-friction/

water

Temperature control mode

Automatic

Automatic

Automatic

Automatic

Automatic

Automatic

Unloading mode

Pneumatic

Pneumatic

Pneumatic

Pneumatic

Pneumatic

Pneumatic

Motor power(kw)

14/22/7.5

30/42/11

40/55/15

47/67/18.5

60/90/22

83/110/30



200/500 Plastic high speed mixer
