Help CenterSmall Capacity Automatic Aerated Drink Mixer
Related Products
Specifications
aerated drink mixer:1.adopts advanced technology-static mixer
2.high quality water pump and SEIMENS electrical equipme
QHS series cola mixer:
Detailed Information:
The machine is made with the newest technology introduced from Japan. It is in the leading position comparing with similar products in china. The mixer is mainly suitable for mixing process of all kinds of carbonic acid drink. It is also used in mixing of slurry drink, fermented drink and other drinks.
1.Automation with Alarm: The pressure in all tank and the liquid level of the machine are all controlled automatically with PLC. Once a error occurs, the alarm lamp will light and the alarm ring will sound and the mixer will stop automatically.
2.Easy operation and regulation: The operation of the mixer is especially convenient. Only turn around the buttons according to the pre-set program, the normal operation can be carried out. The production capacity ,water-sugar proportion and gas content can be adjusted without exchanging any parts.
3.Even mixing and accurate proportion: One time mixing process is adopted, so the mixture is even. The mixing proportion of water and sugar is strictly controlled with measuring needle valve with fine regulation. Its precision can reach about 5%.
4.Enough gas content: The mixer adopts vacuum desoxidation technology at normal-temperature. Its desoxidation ratio reaches above 90%.1t has a baffle heat exchanger to cool the sugar-water mixture and carry out twice carbonating. So its carbon content is especially high.
Presentation:
| PC(kg/H) | 1500 | 3000 | 4000 | 6000 |
| water-sugar mixing proportion | 3:1-10:1 | 3:1-10:1 | 3:1-10:1 | 3:1-10:1 |
| CO2:H20(volum) | >2.6 | >2.6 | >2.6 | >2.6 |
| inter temperature of the chilled water | 3-5 | 3-5 | 3-5 | 3-5 |
| working pressure of precarbonation vessed and svrup vessel(Mpa) | 0.05-0.08 | 0.05-0.08 | 0.05-0.08 | 0.05-0.08 |
| working pressure of srorage vessel(Mpa) | 0.2-0.5 | 0.2-0.5 | 0.2-0.5 | 02-0.5 |
| PCkg/h | 1500 | 3000 | 4000 | 6000 |
| power(kw) | 1.5 | 2.42 | 3.5 | 5.1 |
| Overall dimensions(mm) | 1200x1000x1800 | 1500x1000x2000 | 1650x1300x2000 | 1900x1300x2250 |
| weight(kg) | 600 | 800 | 1300 | 2500 |
