Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate

Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-1
Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-2
Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-3
Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-4
Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-5
Heat Transfer Media -Oil Heating Boiler Boiler With CE,IBR,ISO,GOST Certificate photo-6
US$ 13,300 - 19,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Natural Circulation
Usage Industrial
Structure Other, oil tube
Pressure Low Pressure
Style Horizontal
Fuel Oil-fired
Place of Origin Henan, China
Brand Name DINGSHENG
Model Number YYW-0.9Y(Q)
Output Other, hot oil
Dimension(L*W*H) 1650*2850MM
Weight 2058KG
Certification ISO9001-2008
After-sales Service Provided Engineers available to service machinery overseas

Heat transfer media -Oil heating boiler  boiler with CE,IBR,ISO,GOST certificate

Product Application



  Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificateHeat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate







Process feature:

low pressure and high temperature

Product feature:

1. High temperature in a low pressure

2. Stable heat system

3. Easily temperature control.

3. High heat efficient

4. Excellent operation control system

5. Safe monitor device

6. Less water, electricity, production cost

Application of Industrial thermal oil boiler  Organic Carrier Boiler .





1.Chemical Industry --polymerization industry ,oil industry, reaction tank,distillation ,enrichment

 2. Plastic industry ---plastic and squeeze to finalize the design

 3. Textile industry --resin stenters ,dyeing machine and the dry room ,high temperature machine,

roller.

 4.Rubber industry -rubber vulcanization heating

 5.Food industry --cooking  dry,vegetable oil refining

 6.Wood industry --heating to finalize the design of chipboard sandwich plate ,wamu board,fiber

 7.Paper industry-multi-layer cardboard of packed carton box ,dying and desiccation

 8.Others-heating of metal electroplating slot ,coating condensation ,drying ,distillation of

pharmaceutical industry, reduction ,concentration,dehydration,airconditioning industry.etc





Specification





PARAMETERS:





Fuel(Gas)Organic Heat-Carrier Boiler

Type

YYW0.24(20)

YYW0.35(30)

YYW0.6(50)

YYW0.9(75)

YYW1.2(100)

YYW1.5(235)

YYW1.8(150)

YYW2.5(200)

YYW3(250)

Rated thermal
power(mw)

0.24

0.35

0.6

0.9

1.2

1.5

1.8

2.5

3

Thermal
efficiency(%)

90

90

90

90

90

90

90

90

90

Rated Steam
Pressure(Mpa)

1

1

1

1

1

1

1

1

1

Maximum working
temperature

350

350

350

350

350

350

350

350

350

Capacity

0.21

0.25

0.28

0.44

0.64

0.793

1.25

1.76

1.9

Circulating oil

40

40

80

80

80

100

100

200

200

Piping connection
diameter(DN)

100

100

100

100

125

125

125

150

150

System installed
capacity(KW)

14

14

22

22

40

40

40

66

70

Size

Diameter

1016

1016

1216

1416

1716

1716

2000

2000

2320

Height

2050

2350

2450

2900

3300

3900

4100

5100

5300





 Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate

Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate





Tubes of  Introduction of organic heat transfer media -Oil heating boiler

Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate





other product in our company:





 Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate

-

Company Introduction

Henan Sheng Zhi han Import and Export Trade Co., Ltd. is vetted and approved by the National Foreign Trade and Economic Cooperation, enjoy the right to operate import and export trade of the joint-stock company. The company diversified mode of operation, import, and export agent for sale, re-export trade, mainly engaged in boilers, reactors, pressure vessels and other mechanical equipment, products are mainly exported to Russia, Mongolia, Korea, Vietnam, Nigeria, Ethiopia, Burma and Southeast Asia, Africa countries and regions.

Certifications





Our Services

Choice serviceWe will give you suggestion how to choose a type which is best for you according to your usage and use areas.

Shipping service: Regular Packing or Nude Packing, suited to land transportation as well as sea transportation. We will ship it as your request .

Design service We will design boil room according to your room and the boiler capacity.

Three guarantees service: The boiler has one- year time from the purchase day and life-time service is offered.

Training service :We also provide necessary training about boiler operation and daily maintenance to local workers.

Heat transfer media -Oil heating boiler boiler with CE,IBR,ISO,GOST certificate
