Home > Products > Pneumatic lifting table > Top Quality Pneumatic Scissor Lift Table
Top Quality Pneumatic Scissor Lift Table
- Port Yantian Port Shekou
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | YJX | |
| Model Number | SYSJ-160T | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Air / Pneumatic | Power | 0kw | |
| Rated Loading Capacity | 180kg | Min. Lifting Height | 450mm | |
| Max. Lifting Height | 950mm | Table Size | 2200*1100mm | |
| Overall Dimensions | 2200*1100*550mm | Weight | 200kg | |
| Certification | CE Certificate | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Top quality pneumatic scissor lift table
This machine is mostly used to pull the whole sofa spring, tensioning elastic belts, glue, paste sponge, palpable leather, testing, packaging and other process.
Smooth operation, easy to operate, can greatly reduce the labor intensity. Product quality and work efficiency can be significantly improved.
Single lifting range within 500. The height of the products is determined by the customer according to their needs.
Table board will be equipped only by request.
With turning top, sofa is more convenient to process.
| Model | Max loading | Lifting height | Air pressure | Dimensions | Weight |
| SYSJ-160T | ≤180KG | 450-950mm | 0.4-0.6Mpa | 2200×1100×550mm | 200KG |
Placstic cover, to prevent water come inside the machine when shipping.
you may be need:
Payment terms: 30%TT in advance, balance against BL copy.
After receiving deposit, we start producing. Within 30 days, products will be ready. Customer or we will arrange the shipment. We will provide packing list, invoice and BL copy to customers after the products had been shiped. Customer will pay the balance against the copy. After receiving balance, we will send original documents to customers.
