Full Automation Nitrogen Generator1) N2 Purity: 99-99.9995%
2) N2 Flow: 3-3000Nm3/h
3) N2 Pressure: 1-8 bar
4) Small Size
Full Automation Nitrogen Generator
1) Compact structure
2) High Perfomance
3) Low energy consumption
4) Stable and reliable operation
1,The Application Range of Full Automation Nitrogen Generator
Its suitable to use in gas-adjusting package and nitrogen package of fruits, vegetables, flowers, tea leaves and puffed food, custard pie, milk bread, European-style egg roll, various cookies, farm products and local special products, such as rice, seed and chestnut, etc.
2,Process Principle of Full Automation Nitrogen Generator
Compressed air flows into small nitrogen generator through filter. Oxygen is adsorbed by molecular sieve under the action of food carbon molecular sieve. Nitrogen is conveyed to place or mixed with other gases from outlet. Pressure-varying adsorption adopts the principle of “one unit working while another unit is reproducing” in order to achieve recycling use.
3,Main Characters of Full Automation Nitrogen Generator
1, The equipment adopts the brand-newly-designed filling technique and the service.
2,Special bypass design ensures lower energy consumption and higher yielding results.
3,Imported integrated pneumatic valve with original packaging guarantees the serviceablility in a greater degree.
4,Computer-aided operation with the simple technical design makes for easy maintenance of the equipment.
4,Technical Parameters of Full Automation Nitrogen Generator
Nitrogen-making capacity |
5Nm³/h |
Power |
5W |
Purity |
≥99.5% |
Dew point |
≤-38oC |
Air source pressure |
0.8-1.0Mpa |
Nitrogen-making pressure |
0.1-0.65Mpa |
Shape and dimension |
590×570×1230mm(L×W×H) |
Voltage |
220V 50HZ |
Weight |
150kg |
