Factory price,EXW,20-100KVA YANGDONG Diesel generator set
- 3000 Set / Sets per Month
- fuzhou YANGDONG Diesel generator set
- T/T Credit Card
Product Details
| Place of Origin: | Fujian, China | Brand Name: | DEPOWER | Model Number: | DY20-200 YANGDONG Diesel generator set |
| Output Type: | AC Three Phase | Speed: | 1500/1800 | Frequency: | 50/60 |
| Rated Power: | 20-100KV | Rated Voltage: | 220,110,230,240,380,400,440,415V | Rated Current: | YANGDONG Diesel generator set |
Product Description
2%off promotion,20-100KVA YANGDONG Diesel generator set
It is our promotion time,you can easy get 1%-3%discount now,Contact us now!!
1.As the manufacturer with more 15years experience, 411workers, USD75,632,679.00 turnover in 2013,we can supply the better goods and more professional service for you.
2.due to our rich technical force,advanced equipments and skilled workers,we can meet any high quality request and make goods accord with your any design
3. All of our products is 100%copper and be strictly tested for 2-hours before shipment
4.we will offer any parts you need all the time,not only warranty time.
We can produce Diesel generator(2-2000KW), Gasoline generator (0.65- 7KW), LPG&Gas generator(1.8- 300KW), Pump(1''-4''). Cooperate with CUMMINS,PERKINS,DEUTZ,Holland,WEICHIA,WEIFANG,XICHAI,QUANCHAI,YANGDONG,SHANGCHAI engine etc for many years, Voltage,frequency,phase can be made accord with your need.They have passed CE,ISO,NCOPS certificates
Need more detailes informaion or price list,please contact us
| Model | DY-20 | DY-30 | DY-38 | DY-90 | DY100 |
| Rated frequency (Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated output(KVA/KW) | 20/16 | 30/24 | 38/30 | 90/72 | 100/80 |
| Max. ouput (KVA/KW) | 22/17.6 | 33/26.4 | 42/33 | 99/80 | 110/88 |
| Rated voltage (V) | 400/230,380/220,415/240 | 400/230,380/220,415/240 | |||
| Rated current (A) | 25 | 36 | 52.4 | 97 | 122 |
| Rated speed (r/min ) | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 |
| Phase NO. | 3-phase,four wires Y type connection | 3-phase,four wires Y type connection | |||
| Power factor (cosφ) | 0.8(lag) | 0.8(lag) | 0.8(lag) | 0.8(lag) | 0.8(lag) |
| Insulation grade | H | H | H | H | H |
| Pole number | 4 | 4 | 4 | 4 | 4 |
| panel type | Digital Panel | Digital Panel | Digital Panel | Digital Panel | Digital Panel |
| Overall dimension: L×W×H(cm) | 170*85*100 | 215*90*116 | 215*95 *121 | 280*106*167 | 280*106*167 |
| Dry weight (Kg) | 687 | 880 | 950 | 1160 | 1250 |
| Working assorting weight(Kg) | 725 | 920 | 995 | 1230 | 1300 |
| Noise Level(7M) db(A) | 73 | 73 | 73 | 73 | 73 |
| Engine Model | YSD490 | Y4100 | Y4100ZD | 6105D | 6105ZD |
| Engine type | four-cylinder, 4-stroke, water cooled, direct injection, in-lined, turbocharge | six-cylinder, 4-stroke, water cooled, direct injection, in-lined, turbocharge | |||
| Standby power Kva | 33 | 43 | 57 | 120 | 122 |
| Base output power Kva | 29 | 38 | 53 | 113 | 114 |
| Cylinder quantity | 4 | 4 | 4 | 6 | 6 |
| Air intake way | Air-air after-cooled,turbo-charged | Air-air after-cooled,turbo-charged | |||
| Displacement L | 3.9 | 3.67 | 4.329 | 6.494 | 6.494 |
| Cylinder bore*stroke mm | 102*120 | 100*115 | 105×125 | 105×125 | 105×125 |
| Engine speed rpm | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 |
| Compression ratio | 19:01 | 19:01 | 17:01 | 17:01 | 17:01 |
| Fuel consumption g/kW.h | ≤253 | ≤252 | ≤251 | ≤251 | ≤249 |
WOODCASE or PLYWOOD CASE,18-23days
