Specifications
CE,ISO,160KW 200KVA Xichai diesel generator1)Easier operat&maintain,more stable
2)Part sent by DHL during 3days
CE,ISO,160KW 200KVA Xichai diesel generator
It is our promotion time,you can easy get 1%-3%discount now,Contact us now!!
1.As the manufacturer with more 15years experience, 411workers, USD75,632,679.00 turnover in 2013,we can supply the better goods and more professional service for you.
2.due to our rich technical force,advanced equipments and skilled workers,we can meet any high quality request and make goods accord with your any design
3. All of our products is 100%copper and be strictly tested for 2-hours before shipment
4.we will offer any parts you need all the time,not only warranty time.
We can produce Diesel generator(2-2000KW), Gasoline generator (0.65- 7KW), LPG&Gas generator(1.8- 300KW), Pump(1''-4''). Cooperate with CUMMINS,PERKINS,DEUTZ,Holland,WEICHIA,WEIFANG,XICHAI,QUANCHAI,YANGDONG,SHANGCHAI engine etc for many years, Voltage,frequency,phase can be made accord with your need.They have passed CE,ISO,NCOPS certificates
Need more detailes informaion or price list,please contact us
| Model | DX200 |
| Rated frequency (Hz) | 50/60 |
| Rated output(KVA/KW) | 200/160 |
| Max. ouput (KVA/KW) | 220/176 |
| Rated voltage (V) | 400/230,380/220,415/240 |
| Rated current (A) | 243 |
| Rated speed (r/min ) | 1500/1800 |
| Phase NO. | 3-phase,four wires Y type connection |
| Power factor (cosφ) | 0.8(lag) |
| Insulation grade | H |
| Pole number | 4 |
| panel type | Digital Panel |
| Overall dimension: L×W×H(cm) | 318*120*167 |
| Dry weight (Kg) | 1800 |
| Working assorting weight(Kg) | 1900 |
| Noise Level(7M) db(A) | 73 |
| Engine Model | CA6DL1-24D |
| Engine type | six-cylinder, 4-stroke, water cooled, direct injection, in-lined, turbocharge |
| Standby power Kva | 233 |
| Base output power Kva | 225 |
| Cylinder quantity | 6 |
| Displacement L | 14 |
| Cylinder bore*stroke mm | 140*152 |
| Engine speed rpm | 1500/1800 |
| Compression ratio | 17:01 |
| Fuel consumption g/kW.h | ≤249 |
| Fuel tank capacity L | 120 |
| Continuous runnning time h | 7 |
| Starting system | 24V electric starter |
We offer 18moths after-sales serviceand 1% free parts. If the problem is caused by our technology,we will be responsible for that,even we can send the replacement to youror send our enginer to your country if it is serious.If need and your quantity is enough large,we can send enginer to your country to help you such as installment orteach you some maintenance knowledge and how to solve some problem that you frequently meet. For the parts, they will be sent out during 3days at most after receiving your request..Samples are available and OEM can be provided.
WOODCASE or PLYWOOD CASE,18-23days for samples,23-28days for containers
