CVT8050-NC China vertical turret lathe cnc vertical turret lathe
Machine picture:
Technical parameter:
Item |
Unit |
Specification |
||
Processing ability |
Max. swing diameter |
mm |
1000 |
|
Max. turning diameter |
mm |
800 |
||
Max. height of workpiece |
mm |
500 |
||
|
Spindle
|
Speed range |
r/min |
10~600 |
|
Chuck diameter |
mm |
630(optional hydraulic chuck) |
||
Spindle end type |
|
A2-11 |
||
Spindle bearing(front) |
mm |
260 |
||
X/Z |
X axis travel(half-close control) |
mm |
-50,+500 |
|
Z axis travel(half-close control) |
mm |
500 |
||
X axis fast moving |
m/min |
12 |
||
Z axis fast moving |
m/min |
8 |
||
Motor output power |
Spindle motor(rated/30min) |
kW |
30 |
|
X axis servo motor |
KW |
3.5 |
||
Z axis servo motor |
KW |
3.5 |
||
Tools holder |
Tools holder type |
station |
4(optional eight square ram single tool holder) |
|
Circle cutter size |
mm |
32X32 |
||
Precision |
Processing precision |
|
IT6 |
|
X/Z position precision |
mm |
0.018/0.020 |
||
X/Z repeat position precision |
mm |
0.075/0.015 |
||
Overall size of machine |
mm |
3000X2800X3600 |
||
Machine weight |
Total weight |
Kg |
6800 |
|
System |
CNC |
|
SIEMENS 828D/GSK980TDc |
|
Note: Manufacturer reserves the right to improve & modify without prior notice.
Features:
The machine is developed with dedication to adapt to engineering machinery, circular knitting machine, motor parts machining. The workpiece adopt hydraulic automatic clamping or manual clamping, it is easy for user choose. The lathe is mainly made up of spindle, base, bridge beam, tool holder etc. It has advantage of high speed, high torque, high rigidity, which the best choose processing for variety complex plate-parts, short shaft parts.
Packaging detail: Dismantled into fumigated wood cases, loaded into containers and fastened by iron cable.
Shipping: 2-3 months
Engineers available to service machinery overseas.
Workshop video
Production equipment
Basic Information
Product/Service (We Sell): Single & Double columns Vertical Lathe, CNC single & double columns Vertical Lathe, Horizontal milling & boring machines etc.
Main products:
Single-column vertical lathe: C5112, 5116E
Single-column CNC vertical lathe:CK518, CK5112G, CK5116G
Double-column programmed vertical lathe:CVT280, 350,400,500,630
Double-column CNC vertical lathe: SCVT280,350,400,500,630
Horizontal milling & boring machine: TX6111T, TX6111T/1, TX6111T/2
Factory Information
Factory Size (ters): 250 acres
Factory Location: Fujian, China
Number of Production Lines: 3
Number of R&D Staff: 21 - 30 People
Number of QC Staff: 21 - 30 People
Contract Manufacturing: OEM Service Offered Design Service Offered
Installation: Engineers available overseas
Payment terms: TT with 40% downpayment; 100% LC at sight
Trade terms: Depend on discussion
Guarantee and After-sale Service
One year guarantee for whole machine
24 hours technical support by e-mail or by fax
Calling or door-to-door service
User English manual and detailed videos
Please contact us if you have any questions or needs about our products. Thanks.
Our other machines you may interesting
