160mm PSAM Magnetic card reader RFID emv reader and writer
Features:
1. Can read magnetic/PSAM/EMV/RFID card, can write RFID/IC card.
2. Easy to use in Restaurant/Hotel/Supermarker/Finance
3. USB & COM interface
4. Can prevent the thievery.
| Name | 160mm PSAM Magnetic card reader RFID emv reader and writer |
| Model | CCS-160 |
| Color | Black |
| Read and write Type | magnetic /IC chips /13.56mhz RFID NFC /PSAM |
| Magnetic card | |
| Selectable tracks | YES |
| Read card | 1/2/3tracks |
| Swipe | Double direction |
| Head life | Approx 500,000 passes |
| Parity and LRC checking | Built-in, audible and LED good read and error indicator |
| Cards supported | ISO 7811,AMMVA,CADMV |
| Communications | USB2.0,USB-OTG(Android 3.1 above) |
| Swipe speed | 3 ~ 60 inches per second |
| Maximum power consumption | 100mV |
| Temperature |
Commercial-grade:-20°∼ 60 °C Industrial-grade:-20°∼ 60 °C |
| Humidity | 90% non- condensing |
| Anti-static interference | 15KV |
| Magnetic interference resistance | 19Oersted |
| Vibration resistance | Amplitude 0.35mm,Frequency 10-55Hz,Three axis directions sweep vibration |
| Insulation Resistance | Hot and humid circumstances(40°,95%) Insulation resistance should not be less than 5MΩ |
| Dimension | 160mm(L) ×45mm(W) × 45mm(H) |
| Weight | 180g |
| RFID card | |
| Operating Frequency | 13.56 MHz |
| Smart Card Interface | ISO14443-A, Mifare |
| Sensing Distance | About 0-5cm |
| Programmable sound | ON or OFF |
| Cards supported | ISO14443A,MifareOneS50,MifareOneS70,MF3 DESFIRE, Ultralight, ISO14443B ,SONY felica |
| PSAM card | |
| Head life | Approx 200,000 passes |
| Communications | USB |
| Cards supported | ISO 7816-3 |
| Operating system | Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux |
| IC Card | |
| Cards supported |
AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,SLE4418/4428, ISSI 24C01A/16,ISO7816-(1-4) (T=1, T=0) |
Logo, color, shape customize available;
Widely used in Market Restaurant Shop Bank and etc.
We are a 11 years supplier on alibaba. We mainly manufacture Monitors, POS Machine and related Accessories. We can provide 12 months warranty for all products.
Trade Assurance. It can safeguard your payment to us and ensure us fulfill our obiligations regarding order delivery and product quality.
We also supply other types of card reader and writer, the price and quality is more competitive than other supplier.
If you have requirement, please feel free to contact me for more information.
