Help CenterRSPS-40JF STEAM Stainless Steel Diesel Solenoid Valve
Related Products
-
RSPS-25F Flange Hot Water Zero-pressure Solenoid Water ValveNegotiableMOQ: 1 Set -
RSPS-15J Metal Cover Coil IP 54 Steam Solenoid ValveNegotiableMOQ: 1 Set
-
Steam ValveUS$ 10 - 100MOQ: 10 Sets
-
2 Way Steam Brass Solenoid Valve (RSPS-20N)NegotiableMOQ: 10 Sets
-
Steam Solenoid ValveUS$ 20 - 100MOQ: 1 Set
Specifications
diesel solenoid valveMedia: Steam, hot water, air, oil (below 20cst)
Sealing material: PTFE
diesel solenoid valve
Valves available in normally closed and normally open constructions.
Available in either AC or DC operated with plastic bodies/ stainless steel/ tube/plunger / soft magnetic alloy core.
therefore the price is lower compared with that of brass and stainless steel.
Solenoid semi-direct operated valves available in normally closed constructions. Available either AC or DC operated with cast iron body material and flange connection for a wide variety of applications. Diaphragm(PTFE) from 1/2 to max 2”, Our most economical, high flow valve available. Stainless steel tube and plunger and also soft magnetic alloy core.
-- Media: Steam, hot water, air, oil (below 20cst)
--Function type: Normally Closed (N/C)
--Pressure: 10 bar
--Temperature: -5 ÷180°C
--Mode of action: Semi-direct lift type
--Body material: Stainless
-- Sealing material: PTFE
--Protection class: IP54
Model |
RSPS-15 |
RSPS-20 |
RSPS-25 |
RSPS-32 |
RSPS-40 |
RSPS-50 |
RSPS-20F |
RSPS-25F |
RSPS-32F |
RSPS-40F |
RSPS-50F |
|
Connection pipe size |
1/2" |
3/4" |
1" |
1¼" |
1½" |
2" |
Flange 3/4" |
Flange 1" |
Flange 1¼" |
Flange 1½" |
Flange 2" |
|
Orifice Size |
mm |
15 |
20 |
25 |
32 |
40 |
50 |
20 |
25 |
32 |
40 |
50 |
Cv Value |
4.8 |
8.5 |
14 |
20 |
31 |
51 |
8.5 |
14 |
20 |
31 |
51 |
|
L |
mm |
63 |
81 |
90 |
96 |
116 |
147 |
107 |
123 |
135 |
155 |
190 |
H |
mm |
132 |
148 |
158 |
183 |
182.5 |
194 |
200 |
215 |
251 |
260 |
277 |
H1 |
mm |
117 |
131 |
136 |
157 |
152.5 |
174 |
131 |
136 |
157 |
152.5 |
174 |
Power |
AC:220V~AC:230V 22VA |
AC:220V~AC:230V 30VA |
AC:220V~AC:230V/50-60HZ 38VA; AC110 ~AC:120V/50-60HZ 35 VA; DC24 56W; Range:±10% |
|||||||||
Medium temperature |
-5 ÷180 |
|||||||||||
Pressure |
bar |
0÷10 |
||||||||||
RSPS-40F: 2 way steam IP54 diesel copper solenoid valve
RSPS-40F: 2 way steam IP54 diesel stainless steel solenoid valve
