Help Center2 Way Steam Brass Solenoid Valve (RSPS-20N)
Related Products
-
Steam Solenoid ValveUS$ 20 - 100MOQ: 1 Set -
Steam RSPS-15J Solenoid ValveUS$ 20 - 100MOQ: 1 Set
-
RSPS-40J 2 Way Semi-direct Acting Steam SUS304 Solenoid ValveUS$ 40 - 175MOQ: 1 Set
-
RSPS-25F 2 Way Semi Direct Acting Steam Magnetic Oil ValveNegotiableMOQ: 10 Sets
-
RSPS-20N Plastic Coil IP 65 Steam High Temperature Solenoid ValveUS$ 33 - 185MOQ: 50 Units
Specifications
Solenoid valve1) Piston operated for steam medium
2) Temperature up to 150 degrees
Solenoid valve
1) Body material: brass
2) Operating type: normally closed
3) Mode of action: 2/2-way, semi-direct lift type
4) Sealing material: PTEE or Viton; PTEE is standard
5) Coil grade: class H, IP54 / IP65
6) Suitable for high temperature applications
7) Connection pipe size: PT 1/2" - 2", flange 3/4" - 2"
OPTIONS
EPDM (E): suitable to water, hot water, gas, Freon, the MAX. 120 °C. The coil is plastic coil, IP65.
Viton (V): suitable to hot water, acid, alkali, chemical salt, oil and hydrocarbon; the MAX.150°C ; The coil is plastic coil, IP65.
How to order
Valve type |
Connection pipe size |
Connection |
Voltage |
Seal |
RSPS |
---15 |
|
---DC:24V |
|
|
15 40 |
Blank: Thread |
AC220V |
Blank :PTFE |
|
20 50 |
F: Flange |
AC110V |
V:Viton |
|
25 |
|
DC:24V |
E:EPDM |
|
32 |
|
DC:12V |
|
PARAMETERS
Model |
RSPS-15 |
RSPS-20 |
RSPS-25 |
RSPS-32 |
RSPS-40 |
RSPS-50 |
RSPS-20F |
RSPS-25F |
RSPS-32F |
RSPS-40F |
RSPS-50F |
|
Connection pipe size |
1/2" |
3/4" |
1" |
1¼" |
1½" |
2" |
Flange 3/4" |
Flange 1" |
Flange 1¼" |
Flange 1½" |
Flange 2" |
|
Orifice Size |
mm |
15 |
20 |
25 |
32 |
40 |
50 |
20 |
25 |
32 |
40 |
50 |
Cv Value |
4.8 |
8.5 |
14 |
20 |
31 |
51 |
8.5 |
14 |
20 |
31 |
51 |
|
L |
mm |
63 |
81 |
90 |
96 |
116 |
147 |
107 |
123 |
135 |
155 |
190 |
H |
mm |
132 |
148 |
158 |
183 |
182.5 |
194 |
200 |
215 |
251 |
260 |
277 |
H1 |
mm |
117 |
131 |
136 |
157 |
152.5 |
174 |
131 |
136 |
157 |
152.5 |
174 |
Power |
AC:220V~AC:230V 22VA |
AC:220V~AC:230V 30VA |
AC:220V~AC:230V/50-60HZ 38VA; AC110 ~AC:120V/50-60HZ 35 VA; DC24 56W; Range:±10% |
|||||||||
Medium temperature |
-5 ÷180°C |
|||||||||||
Pressure |
bar |
0÷10 |
||||||||||
---RSPS-25: 2way copper IP54 hot water oil semi-direct steam solenoid valve
---RSPS-25J: 2way copper IP54 hot water oil semi-direct steam solenoid valve
---RSPS-25NJ: 2way copper IP65 hot water oil semi-direct steam solenoid valve
---RSPS-40F: 2 way brass hot water steam .oil IP54 flange solenoid valve
--- RSPS-40JF: 2 way Stainless steel hot water steam .oil IP54 flange solenoid valve
