PP hollow sheet for box useful

Specifications

PP Corrugated sheet
Material:PP
width:1-2.05mm
Thickness:2~10mm
Color:White,Transparent,Red,Yellow,Blue,Green,etc

PP Corrugated packaging box



Introduction:

PP corrugated sheet are light, high strength, anticorrosive, waterproof and moisture proof, etc. They can be used to display, screen printing, packaging. S-corrugated board is the one of  Oursign's special products. The package box made of this media is with high intensity and long durability. And this media can be reused and easily be cleaned. So it can also be made to the products with the function of electric conduction, and made to the products which can anti static and anti UV. It's widely used in the field of advertisement, package and electronics.





Features:

1. Light weight.

2. High strength.

3. anti-corrosive.

4. water proof and moisture proof.

5. Weather resistant (UV, rain, typhoon and frost).
6. anti-static.



Application:

1. Billboard .

2. screen printing.

3. Exhibition booth decoration.

4. Displays (indoor and outdoor).

5. packing box.

6. Insulator, cushion material, tray.



 Specification:

Physical property	Value
Thickness ±0.1(mm)	2	3	4	5	6	7	8	9	10
Width(mm) and Length(mm)	≤2050,limitless					≤1250,limitless
Weightg/m2)	450±10	500±10	700±10	900±10	1200±20	1400±20	1600±20	1800±20	2000±20
Tearing Strength at break (N/mm)	≥230	≥260	≥300	≥350	≥400	≥450	≥510	≥580	≥650
Elongation rate at break%	≥52	≥52	≥52	≥52	≥52	≥52	≥52	≥52	≥52
Surface Compressive StrengthN/cm2	≥800	≥1000	≥1500	≥2500	≥3000	≥3500	≥4000	≥4500	≥5000
Perpendicular Compressive StrengthN/cm2	≥95	≥150	≥350	≥500	≥600	≥700	≥750	≥800	≥1000
Tearing StrengthN/mm	≥50	≥60	≥80	≥100	≥130	≥150	≥170	≥190	≥210
Colors	Transparent ,White,Red,Yellow,Blue,Green, Black,Gray.





Note :
1. The standard Width and length:1.22m*2.44m

2. Special Specification (length, Width, Thickness, Weight)can be specified.
