High quality diamond rock drill bit for hard rock drilling
diamond rock drill bit
1.balanced force design
2.reasonable layout of PDC cutters
3.strong aggressiveness
4.high speed
Characteristics of diamond rock drill bit:
-PDC cutters of different features are selected and bit profile design is optimized to suit different drilling
applications in different formations to satisfy different requirements when drilling soft to medium hard formations.
-Cutting structure is force balanced, non-symmetrical blade and wide gage are designed so that the bit
drills more stable and resulting longer working life of the bit.
-Better wear resistance and higher strength of the bit are guaranteed in regard to material and structure by
using matrix body material with self-owned intellectual property rights and combining FEA analysis technology.
-Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to enhance cleaning
and colling effects of the bit to effectively prevent bit from balling.
-CNC sintering process uses full automatic control/ Inside and outside temperature of the bit is monitored
during all procedures to fully embody material properties as well as ensure uniformity and stability of product
quality.
Diamond rock drill bit
PDC stands for Polycrystalline Diamond Compact which refers to the cutters on these drill bits. PDC bits have exceptional rates of penetration when drilling & can out preform other bits in the right conditions. The diamond cutters are 10 times stronger than steel and PDC bits are most effective when drilling through shale, salt, clay, stone, sand, and concrete.
Advantage of diamond rock drill bit:
* Increase penetration rates in oil and gas wells
* Reduce drilling time and costs
* Bit cost varies from 2%-5% of total cost, but bit affects up to 75% of total cost
* Cutters
- consist of thin layer of bonded dimond particles plus a thicker layer of tung sten carbide
* Diamond
- 10x harder than steel
- 2x harder than tungsten carbide
- Most wear resistant material
APPLICATIONS of diamond rock drill bit :
* PDC bits are used primarily in deep and/or expensive wells, and are effectively used in soft-medium hard formations.
* Advances in metallurgy, hydraulics, and cutter geometry
* PDC bits drill longer and more effectively
* Most effective in very weak, brittle formations(Sandy, silty claystone, siliceous shales)
COMMONLY USED A BIT SIZES FOR RUNNING API CASING
|
Casing Size (OD in.) |
Coupling Size (OD in.) |
Common Bit Sizes Used(in.) |
|
4 1/2 5 5 1/2 6 6 5/8 7 7 5/8 8 5/8 9 5/8 10 3/4 13 3/8 16 20 |
5.0 5.563 6.050 6.625 7.390 7.656 8.500 9.625 10.625 11.750 14.375 17 21 |
6, 6 1/8, 6 1/4 6 1/2, 6 3/4 7 7/8, 8 3/8 7 7/8, 8 3/8, 8 1/2 8 1/2, 8 5/8, 8 3/4 8 5/8, 8 3/4, 9 1/2 9 7/8, 10 5/8, 11 11, 12 1/4 12 1/4, 14 3/4 15 17 1/2 20 24, 26 |
Ideal for: environmental drilling, mining, geothermal & construction
diamond rock drill bit selection guide | ||||
No. |
Formation |
IADC code |
Lithology |
Appropriate PDC bit type |
1 |
Very soft |
M123 |
Clay Mudstone Marlite |
KM1944R,KM1952R |
2 |
Soft |
M223 |
Marlite Saline rock Shale |
KM1952R,KM1952GR,KM1952AR,KM1952ARG, KM1652AR,KM1652R,KM1652AGR |
3 |
Medium Soft |
M323 M324 |
Shale Sandstone Chalk |
KM1652DR,KM1662,KM1662GR,KM1953DGR |
4 |
Medium |
M423 M433 |
Sandstone Limestone Shale |
KM1665GR,KM1665ADR,KM1362,KM1365D,KM1375D |
diamond rock drill bit :
diamond rock drill bit types
Packing: Wooden case or as clients' request.
Shipping: By sea or by air for exporting goods.
1.We will keep track of each customer to get the feedback of product quality and service. And we will make an amendment according to your feedback.
2.If the product size is wrong, we will send the right one freely.
3.We guarantee the high quality. Please feel free to contact us if you found any damage. We will solve the problems ASAP.
4.We can provide product repair services.
The optimaler price, the best quality, the fastest speed, the best service.Your every piece of advice to us we will be very seriously treatment. If you have any suggestion to us, please surely tell us by mail in a timely manner You are not just a visitor, but our partner in common progress.
Sincerely hope to cooperate with you.
Cangzhou Lockheed Drilling Equipment Parts Co., Ltd. is a professional manufacturer of drilling equipments and tools which is located in Hejian City, the centre of the triangle of Beijing, Tianjin and Shijiazhuang, enjoying convenient transportation.
Our products Including below three series with full model types:
Drilling Bit: rock roller bit,tricone bit,pdc drill bit,single bit,cone bit and hole opener;
Drilling Equipment Parts: manual tong,elevator,slips,stabilizer;
Workover Fishing Tools: releasing spear,junk basket, overshot,reversing sub,die collar, fishing tap etc.
Our staff are professional and experienced. By the hard efforts and united cooperation, we have established a wide sale network. Striving for excellent quality, better price and perfect service. Welcome new and old customers to order.
1. How to order the products?
Answer:
Send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.
2. About lead time and shipping time?
Answer :
The lead time depend on quantity of order. Usually shipped by sea, small order or urgent order we can send you by air after received your agreement.
According the distance from china to your port, usually from China to European about 25 days. To West of American 20 days.
3.Can I expect a quality products?
Answer :
Yes. All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
Pls do not forget to add below information in your inquiry which will help us to give you the exact quotation at the first time:
1) the size of the tricone bit you need
2) the IADC code of the bit, like 537G
3) the drilling information of the layer
4) quantity
Welcome visit our page, any need pls feel free to contact me.
I'm Bonnie, always at your service!
