Home > Products > Glass Cutting Machine > glass cutter
glass cutter
- 300 Set / Sets per Month
- shanghai port
- T/T
Product Details
Condition: | New | Machine Type: | Glass Cutting Machine | Production Capacity: | 300 |
Place of Origin: | Jiangsu, China | Brand Name: | Sunrise | Model Number: | SQ4020 |
Voltage: | 380V | Power(W): | 30KW | Dimension(L*W*H): | load in a 40GP container |
Weight: | 5 TON | Certification: | CE | Warranty: | ONE YEAR |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Used in glass cutting
(1)cut glass in appliance (table of gas stove, range hood, disinfection cabinet and TV )
(2)lamps and lanterns
(3)Sanitary product
(4)Architecture,art glass
(5)Auto glass
parameter Model | CUX400-SQ4020 | |||
X axis travel | 4.00M | |||
Y axis trave | 2.00M | |||
Z axis travel | 0-150mm | |||
Type of machine | Cantilever Type | |||
Max material thickness | 150mm | |||
Control Accuracy | ±0.002mm | |||
Cutting Accuracy | ±0.1mm | |||
Max working pressure | 60000 psi (400Mpa) | |||
Motor Power | 22kw/30kw | |||
High pressure pump type | intensifier type, 30 HP (Minimum) | |||
Power | 380 Volt / 3 Phase / 50 Hz | |||
Cut range material | from metal, steel ,glass ,stone ,granite, ceramic ,marble,foam, plastic even food is well. | |||
Cutting Characteristics: | 1. versatility ,ld cutting process3.uess no heat |
Water jet machines—fast speed, able to cut thick material, good accuracy and finishing surface. Cuts virtually anything with no heat affected zone (HAZ).Some burr occur near cut. Water jet is widely used as metal cutting machine, glass cutting machine, ceramic tile cutting machine, marble cutting machine, and granite cutting machine.
