Specifications
1)professinal OEM factor2)quick leadtime
3)fire proof
4)strict quality check
12" Insulated flexible aluminum air duct
ADIF - 1 layer Aluminum/ 1 layer Polyester (out sleeve)
Fiberglass blanket insulation
1 layer Aluminum/ 1 layer Polyester/ 1 layer Aluminum (core duct)
Application
ADIF is a range of fully flexible insulated ducting. provides outstanding resistance and durability.
ADIF is suitable for use with heating, ventilation and air conditioning systems.
Technical data (Xuanyuan Factory)
Material of Core Duct |
Aluminum/Polyester, Steel wire |
||
Thickness of Core Duct |
0.032mm |
||
Fire Resistance |
Yes,Good |
||
Thickness of Insulation |
25mm/50mm (Fiberglass) |
||
Density of Insulation |
16kg/m3/32kg/m3 (Fiberglass) |
||
Air Velocity |
30 m/s |
||
Operating Pressure |
2500 Pa |
||
Operating Temperature Range |
-30 °C/+140 °C |
||
Available Diameters |
75mm - 600mm |
||
Available Lengths |
5m,6m,7,5m,10m |
||
Packing |
Paper carton box with Polyethylene bag inside |
||
Diameter of Duct (mm) |
Steel wire thickness (mm) |
Steel wire spacing (mm) |
|
102mm |
0.9mm |
30mm |
|
127mm |
0.9mm |
30mm |
|
152mm |
1.0mm |
35mm |
|
203mm |
1.1mm |
40mm |
|
254mm |
1.2mm |
45mm |
|
305mm |
1.2mm |
45mm |
|
315mm |
1.2mm |
45mm |
|
400mm |
1.2mm |
45mm |
|
QUANTITY |
Mini order or massive production available |
SHIPMENNT |
usually 10-30 days, it depends on the ordered qty |
PORT |
Shanghai port or Ningbo port |
PAYMENT |
30% deposit before the production and 70% balance before the shipment, T/T, |
SAMPLES |
Samples is available,by Express |
Why buy from us
1. Your inquiry will be replied with 24 hours
2. We have been in this industry for more than 10 years
3. We only support good quality products to Customers
4. Samples are available by Express 3-5 days
5. We can offer EXW,FOB,CIF price as Customers request.
After-sales service commitment
1. Product information service for the customer free of charge;
2. If our company receive user feedback quality problem, we will timely
communication with customers, and make up for the customer in time
when have problems of products.when necessary, make up for economic losses.
