Replace MICROTEST(5238)transformer test system by (SS3302)automatic transformer test system

Cartons, total 2PCS cartons, tester packing size L56.5*W42.5*H30.5CM,scaning box packing size L44*30*24CM, total packing weight 16KG.for SS3302 automatic transformer test system.

  SS3250/3252/3302 automatic transformer test system

Description of SS3250/3252/3302 automatic transformer test system :
The SS3250/3252/3302 automatic transformer test system  is a precision test system, designed for transformer production line or incoming/outgoing inspection in quality control process, with high stability and high reliability. With the enhanced capability in turn ratio measurement, they can solve the measuring problems of low coupling coefficient, transformer's turn ratio and turn number with more precise measurement. In addition to transformer scanning test function, the 3302/3252 have LCR Meter function. Operator-friendly and value-added, they can help you reduce production cost greatly.

Feature of SS3250/3252/3302 automatic transformer test system :
1. Test frequency: 20Hz-200KHz/1MHz, 0.02% accuracy.
2. Basic accuracy: 0.1%
3. Output impedance modes, measurement results are compatible with other well-known LCR meters.
4. Enhanced Turn Ratio measurement accuracy for low permeability core
5. Fast Inductance/Turn Ratio measurement speed up to 80 meas. /sec
6. Fast DCR measurement speed up to 50 meas. /sec
7. Bias current source directly control capability (3252/3302)
8. 320x240 DOT-matrix LCD display
9. Support versatile standard and custom-design test jigs
10. Four-terminal test for accurate, stable DCR, inductance and turn ratio measurements
11. Build-in comparator; 10 bin sorting with counter capability (3252/3302)
12. 2M SRAM memory card, for setup back-up between units
13. Standard RS-232, HANDLER, PRINTER interface
14. 50 internal instrument setups for store/recall capability

Order items of SS3250/3252/3302 automatic transformer test system :
A. SS3250/3252/3302
B. 3001A(scaning testing box)
C. Universal fixture
D. Custom-made fixture (optional)
E. Memory card (optional)

  SS3250/3252/3302 automatic transformer test system

Specification of SS3250/3252/3302 automatic transformer test system  :

Pictures of SS3250/3252/3302 automatic transformer test system
