Help Center3inch 10W Dimmable SMD LED Down Light Kit Cutout 90mm With CE SASO IC-F Certificated
Related Products
-
15W Dimmable LED Downlight New ProductsUS$ 4.9 - 5.8MOQ: 30 Pieces -
2015 New Heat-conductive PlasticLED Downlights 11W, Nichia LED,US$ 3.5 - 4.2MOQ: 100 Pieces
-
4inch 15W 1250lm SMD Dimmable LED Down Light CE SASO IC-F CertificatedUS$ 4.9 - 5.8MOQ: 30 Pieces
-
COB LED Light 4inch 14W COB Dimmable LED Down Light 850lmUS$ 9.6 - 12.2MOQ: 5 Pieces
-
Chip LED Nichia COB LED Down Light Dimmable 14WUS$ 9.6 - 12.2MOQ: 5 Pieces
Product feature
Adopted high quality SMD LED, high CRI 80.
Lumens of cool white up to 870lm, and of warm white up to 780lm.
Aluminum +Heat-conductive plastic material allows best value price with good heat elimination.
Integrated internal driver design makes it easy for installation.
Smart dimmable down to 5% with most trailing edge and leading dimmers or dimming systems.
CE/IC-F approved internal driver with PFC>0.9.
Full range color temperature 3000K, 4000K, 6000K for wide selection.
| Model Number | D3010V-DIM(WW)/D3010V-DIM(CW) |
| Power consumption | 10W |
| LED | SMD |
| CRI | 85 |
| Efficiency(lm/W) | 87lm/W / 78lm/W |
| Colour Temperature | 2700K/3000K/4000K/5000K/6000K |
| Beam Angle | 90° |
| Input Voltage | 220-240VAC |
| Lumens | 870lm / 780lm |
| Material | Aluminum +Heat-conductive plastic |
| Cutting Size(mm) | Φ90-100 |
| Dimension(mm) | Φ113.5×65.5 |
| Net Weight | 280g |
| Lifetime(hr) | 40000 |
| Working Temperature | -5℃+35℃ |
| Dimmable | dimmable or non-dimmable both available |
Application:
- Area: Indoor use only.
- Purpose: Accent lighting, local lighting.
- General lighting, BAR/Restaurant, Hotel, Store, Hall / Lobby, Art gallery,
- Jewelry store, Museum, Theater, School...
General characteristics
Model Number |
Product name |
Material |
Driver |
IP Rating |
Dimension (mm) |
Cut size(mm) |
Net Weight |
Lifetime (hr) |
|
D3010V-DIM(WW) D3010V-DIM(DW) D3010V-DIM(CW) |
LED Down Light |
Aluminum +Heat-conductive plastic |
Internal |
IP20 |
Φ113.5x65.5 |
90-100 |
280g |
25000 |
Product show
Packaging information
Packing: 40 PCS / carton | ||
Box |
125×125×95(mm) |
280 g |
Carton |
62×39×30(cm) |
12.50 kg |
individual inner carton for each product, 40pcs/ Outer carton.
WINSUN established in 2008, is a fast developing company who specializes in designing and manufacturing high power LED lights for indoor use like LED Spot Light (MR16 / GU10 / AR111 / PAR Light), LED Down Light, LED Ceiling Light and LED Bulb. All our products use original NICHIA LED with patent design. Having exported to most European countries and Oceania, and was highly praised by our old customers.
For more information please visit:
WINSUN Target
Creat energy saving and environmental protection products and bring them to the whole world.
WINSUN Mission
Produce the most reliable lighting products and let people easy to get them.
WINSUN Core Values
1. High quality wins value
2 .Innovation makes motivation
3. Frank honesty and mutual trust
4. Enterprising spirit and synchronous progress
5. Realistic and insistent
