Product feature
Adopted high quality SMD LED, high CRI 80.
Lumens of cool white up to 870lm, and of warm white up to 780lm.
Aluminum +Heat-conductive plastic material allows best value price with good heat elimination.
Integrated internal driver design makes it easy for installation.
Full range color temperature 3000K, 4000K, 6000K for wide selection.
CE/EMC/LVD approved internal driver with 220-240V input.
| Model Number | D3010V-DIM(WW)/D3010V-DIM(CW) |
| Power consumption | 10W |
| LED | SMD |
| CRI | 85 |
| Efficiency(lm/W) | 87lm/W / 78lm/W |
| Colour Temperature | 2700K/3000K/4000K/5000K/6000K |
| Beam Angle | 90° |
| Input Voltage | 220-240VAC |
| Lumens | 870lm / 780lm |
| Material | Aluminum +Heat-conductive plastic |
| Cutting Size(mm) | Φ90-100 |
| Dimension(mm) | Φ113.5×65.5 |
| Net Weight | 280g |
| Lifetime(hr) | 40000 |
| Working Temperature | -5℃+35℃ |
| Dimmable | Yes or No |
Application:
- Area: Indoor use only.
- Purpose: Accent lighting, local lighting.
- General lighting, BAR/Restaurant, Hotel, Store, Hall / Lobby, Art gallery,
- Jewelry store, Museum, Theater, School...
General characteristics
Model Number |
Product name |
Material |
Driver |
IP Rating |
Dimension (mm) |
Cut size(mm) |
Net Weight |
Lifetime (hr) |
|
D3010V(WW) D3010V(DW) D3010V(CW) |
LED Down Light |
Aluminum +Heat-conductive plastic |
Internal |
IP20 |
Φ113.5x65.5 |
90-100 |
280g |
25000 |
Product show
Packaging information
Packing: 40 PCS / carton | ||
Box |
125×125×95(mm) |
280 g |
Carton |
62×39×30(cm) |
12.50 kg |
individual inner carton for each product, 40pcs/ Outer carton.
