RGX P7.62mm Rgb Led Display Screen Panel

RGX P7.62mm Rgb Led Display Screen Panel thumbnail-1
RGX P7.62mm Rgb Led Display Screen Panel thumbnail-2
RGX P7.62mm Rgb Led Display Screen Panel thumbnail-3
RGX P7.62mm Rgb Led Display Screen Panel thumbnail-4
RGX P7.62mm Rgb Led Display Screen Panel thumbnail-5
RGX P7.62mm Rgb Led Display Screen Panel thumbnail-6
RGX P7.62mm Rgb Led Display Screen Panel photo-1
RGX P7.62mm Rgb Led Display Screen Panel photo-2
RGX P7.62mm Rgb Led Display Screen Panel photo-3
RGX P7.62mm Rgb Led Display Screen Panel photo-4
RGX P7.62mm Rgb Led Display Screen Panel photo-5
RGX P7.62mm Rgb Led Display Screen Panel photo-6
US$ 17 - 18 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
RGX
Model Number:
RGX-P7.62-I-F- SMT led display
Contact Supplier Request Quote Chat Now
Shenzhen RGX Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name RGX
Model Number RGX-P7.62-I-F- SMT led display
Usage Indoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, P7.62MM
Screen Dimension Size by Customize

 RGX P7.62mm rgb led display screen panel





Product Description

  3: Shenzhen RGX P7.62mm indoor full color LED display

RGX P7.62mm led display Specification

Unit Module

Item:

RGX LED Parameter

Model:

P7.62mm indoor Full color led Module

Pixel Pitch:

7.62 mm

Pixel configuration:

3in1 (1R1PG1B SMT 3in1)

Module Size:

244mm * 244mm

Module Resolution:

32dots(W) * 32dots(H)

Module Thickness:

14.85mm

27.15mm(included magnet)

Module Weight:

0.154 KG

Package LED mode:

SMD3528

Max Power:

20W

Pixel Density:

17222 dots / SQM

Driving Method:

Constant Current Driving

Scan Method:

1/8 scan

Interface Way:

HUB 75

Brightness:

≥ 2800CD /SQM

Unit Cabinet

Cabinet Size:

732mm * 732mm (Customize)

Cabinet Composing:

18 pcs

Power Supply Mode:

5V/40A

Cabinet Resolution:

96dots * 96dots

Optimal Viewing Distance:

5-60M (according to the big screen size)

Optimal Viewing Angle:

Horizontal angle: 160 degree;

Vertical angle: 120 degree

Environment Temperature:

Storage: -40 degree `~ +85 degree

Work: -20 degree ~ +60 degree

Relative Humidity:

10% ~ 95%

Power

Operating Voltage:

AC:100V~120V AC:220~240V

Average Power:

180/SQM

Max Power Consumption:

≤ 580W/SQM

Current:

≤ 20mA (single LED)

Control System

Computer:

Pentium4 or above P4 or above

Operate System:

Win98/2000/NT/XP

Control Mode:

Synchronization with PC

Main Technical

Parameter

Driving Device:

IC Constant Current Driving

Refresh Rate:

≥ 600Hz

Gray/Color:

RGB each 256 grade, can display 16.7color

MTPF:

≥ 9000hours

Power Switch:

RGX Automatic Switch

Display Mode:

800*6001024*7681280*960





Show Photo Details:

 RGX P7.62mm rgb led display screen panel

                                                                                                      RGX Indoor rental cabinet

RGX P7.62mm rgb led display screen panel

                                                                                                RGX Indoor Iron rental cabinet

RGX P7.62mm rgb led display screen panel

RGX P7.62mm rgb led display screen panel

RGX P7.62mm rgb led display screen panel



Company Information

  RGX was founded in 2000 year  and has five hundred and fifty workers. There into, 12% is R&D engineer. Our general engineer was famous engineer in LED field, he has 12 years experience in LED product and is very familiar with LED display screen, power supply,  technology and raw materials, we mainly produce middle and high-grade products, and have established strict product quality standards, we produce our product from LED chip to complete led screen assemble finish, that why we can guaranteed our product’s quality



 2: RGX Company photo



RGX P7.62mm rgb led display screen panel



5: Test: Each producing step of P7.62mm full color led display we had strict test.

RGX P7.62mm rgb led display screen panel





7: Installation:

RGX P7.62mm rgb led display screen panel

8: indoor led display System:

RGX P7.62mm rgb led display screen panel







Packaging & Shipping



9: Pack

RGX P7.62mm rgb led display screen panel

10: Transportation

12: Our Advantage:

1)   Competitive price

2)   Professional manufacturer

3)   Exquisite quality

      a:   ISO 9000 and 5S management system

      b:  Each procedure have special machine and QC to supervise and check

      c:  From the material purchasing, all have the special Equipment to stakeout

Perfect service

2-3years guarantee with free charge, maintain in all life

Free training in our company or guide installation and train in customer country or on lone training by long-distance control in internet

Regular training and meeting in each month for all customers, provide strong technology for each customer at the first time



In the end, thank you very much for you time and have good business for you
