IR-Series
PWM Solar charge controller
Features
Self adjust automatically 12V/24V
LED display shows the mode
Three states of charge way
PWM (Pulse Width Modulation)Technology
Programmable Light and Time Control(1-13h)
Electronic protection
Standby Loss less than 5mA
Specification:
Model |
IR1205 |
IR1210 |
IR1215 |
IR1220 |
Rated charging current |
5A |
10A |
15A |
20A |
Rated discharging current |
5A |
10A |
15A |
20A |
Short-current protection |
25A |
25A |
25A |
25A |
System voltage |
12V/24V Auto adapt |
|||
Over current protection |
<1.3 maintain for 60s <1.6 maintain for 5s >1.6 shut down immediately |
|||
Stand-by lost |
<5mA |
|||
Charge voltage drop |
≤0.26V |
|||
Discharge voltage drop |
≤0.15V |
|||
Max solar panel votlage |
21V |
|||
Operating temperature |
-35°C to +55°C |
|||
Equalize charging voltage |
14.8V |
|||
Bulk charging voltage |
14.5V |
|||
Acceptance charging voltage |
14.2V |
|||
Float charging |
13.8V |
|||
Charge return voltage |
13.2V |
|||
Discharge stop voltage |
11.2V |
|||
Discharge return voltage |
12.6V |
|||
Temperature compensation |
N/C |
|||
Control mode |
PWM( Pulse Width Modulation ) |
|||
Maximum wire size |
16AWG |
|||
Size/weight |
82x57x20mm/140g |
|||
Attn:1.All voltage are for 12V system,pls time 2 if you are using 24V system
2.voltage tolerance 1%
3.Product specifications are subject to change without prior notice
