Help CenterIndustrial Sight Glass Indicator
Related Products
-
Flange Sight Glass Level IndicatorNegotiableMOQ: 2 Units -
Pipe Sight Glass Flow Meter With Temperature and Flow DisplayerUS$ 1 - 1,612MOQ: 1 Set
-
Pipe Temperature and Flow Sight Glass/indicatorUS$ 1 - 1,613MOQ: 1 Set
-
Pipe Sight Glass/flow Indicator With Temperature and Flow DisplayUS$ 1 - 1,613MOQ: 1 Set
-
Oil/medical Pipe Sight Glass/ Flow Indicator With Digital OutputUS$ 161 - 1,613MOQ: 1 Set
Specifications
Working Pressure:0.25-2.5MPaMax medium temperature:200C
Material:Carbon steel
Specific requirement can be made by order
Application
GSJ Pipe sight glass is widely used in petroleum,chemicals, pharmaceuticals industry that can observe the the situation of fluid in the pipe directly.
Main technical parameters
Temperature: ≤200°C
Pressure: 0.25-2.5MPa
Structure and Shape dimension
PN=0.25MPa | ||||||
Mark model |
Nominal diameter (mm) |
Shape dimension(mm) |
Glass plate(mm) |
Weight(kg) |
||
H |
L |
Diameter |
Thickness |
|||
GSJ-3-25-0.25 |
25×32 |
260 |
226 |
95 |
15 |
14.3 |
GSJ-3-40-0.25 |
40×50 |
320 |
266 |
140 |
20 |
22.9 |
GSJ-3-50-0.25 |
50×65 |
320 |
266 |
140 |
20 |
24.5 |
GSJ-3-65-0.25 |
65×80 |
360 |
300 |
165 |
20 |
31.3 |
GSJ-3-80-0.25 |
80×100 |
360 |
300 |
165 |
20 |
32.8 |
PN=0.6MPa | |||||
Mark model |
Shape dimension(mm) |
Glass plate(mm) |
Weight(kg) |
||
H |
L |
Diamete |
Thickness |
||
GSJ-3-25-0.6 |
260 |
234 |
95 |
15 |
16.8 |
GSJ-3-40-0.6 |
320 |
278 |
140 |
20 |
28.6 |
GSJ-3-50-0.6 |
320 |
278 |
140 |
20 |
29.8 |
GSJ-3-65-0.6 |
360 |
308 |
165 |
20 |
36.5 |
GSJ-3-80-0.6 |
360 |
308 |
165 |
20 |
46.5 |
