Specifications
Working Pressure:0.25-2.5MPaMax medium temperature:200C
Material:Carbon steel
Specific requirement can be made by order
Application
GSJ Pipe sight glass is widely used in petroleum,chemicals, pharmaceuticals industry that can observe the the situation of fluid in the pipe directly.
Main technical parameters
Temperature: ≤200°C
Pressure: 0.25-2.5MPa
Structure and Shape dimension
PN=0.25MPa | ||||||
Mark model | Nominal diameter (mm) | Shape dimension(mm) | Glass plate(mm) | Weight(kg) | ||
H | L | Diameter | Thickness | |||
GSJ-3-25-0.25 | 25×32 | 260 | 226 | 95 | 15 | 14.3 |
GSJ-3-40-0.25 | 40×50 | 320 | 266 | 140 | 20 | 22.9 |
GSJ-3-50-0.25 | 50×65 | 320 | 266 | 140 | 20 | 24.5 |
GSJ-3-65-0.25 | 65×80 | 360 | 300 | 165 | 20 | 31.3 |
GSJ-3-80-0.25 | 80×100 | 360 | 300 | 165 | 20 | 32.8 |
PN=0.6MPa | |||||
Mark model | Shape dimension(mm) | Glass plate(mm) | Weight(kg) | ||
H | L | Diamete | Thickness | ||
GSJ-3-25-0.6 | 260 | 234 | 95 | 15 | 16.8 |
GSJ-3-40-0.6 | 320 | 278 | 140 | 20 | 28.6 |
GSJ-3-50-0.6 | 320 | 278 | 140 | 20 | 29.8 |
GSJ-3-65-0.6 | 360 | 308 | 165 | 20 | 36.5 |
GSJ-3-80-0.6 | 360 | 308 | 165 | 20 | 46.5 |
