230W Poly Solar Module

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Model Number:

RL-230P

Ningbo Ring Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name RL

Model Number RL-230P

Material Polycrystalline Silicon

Size 1950*982*50mm

Number of Cells 72pcs

Max. Power 230Wp

Specifications

1) A grade cell used
2) Certifications:CE, Rosh, ISO 9001:2008
3) 3 years product warranty and 25 years 80% of power

Maximum power (Wp)	230wp
Maximum power voltage (V)	34.5
Maximum power current (A)	6.65
Open circuit voltage (V)	43.2
Short circuit current (A)	7.52
Number of cells (Pcs)	72pcs(156*156mm)
Size of module (mm)	195099050mm
Maximum system voltage (V)	1000
Temperature coefficients of Isc (%)	0.06+/-0.01%/°C
Temperature coefficients of Voc (%)	-(0.2+/-0.02)mv/ °C
Temperature coefficients of Pm (%)	-(0.5+-0.05)/ °C
Temperature coefficients of Im (%)	+0.1/ °C
Temperature coefficients of Vm (%)	-0.38/ °C
Temperature Range	-40°C~+85°C
Tolerance Wattage (e.g. +/-5%)	+/-5%
Surface Maximum Load Capacity	60m/s(200kg/sq.m)
Allowable Hail Load)	steel ball fall down from 1m height
Weight per piece (kg)	24.2
Junction Box Type	GY-BOX-5B( TUV )
Length of Cables (mm))	900mm
Output tolerance (%)	+/-3%
Frame (Material, Corners, etc.)	Aluminum
Standard Test Conditions	AM1.5 100mW/cm2 25’C
FF (%)	75%
Packing	2PCS/CTN, 330CTN/40 FCL
