Home > Manufacturing & Processing Machinery > Lifting Equipment > Hoist > PA Type Electric Hoist With Remote Control

PA Type Electric Hoist With Remote Control

Name: PA Type Electric Hoist With Remote Control
Brand: Yunxiang
SKU: 105090097
Availability: InStock

PA Type Electric Hoist With Remote Control thumbnail-1

PA Type Electric Hoist With Remote Control thumbnail-2

PA Type Electric Hoist With Remote Control thumbnail-3

PA Type Electric Hoist With Remote Control thumbnail-4

PA Type Electric Hoist With Remote Control thumbnail-5

PA Type Electric Hoist With Remote Control thumbnail-6

PA Type Electric Hoist With Remote Control photo-1

PA Type Electric Hoist With Remote Control photo-2

PA Type Electric Hoist With Remote Control photo-3

PA Type Electric Hoist With Remote Control photo-4

PA Type Electric Hoist With Remote Control photo-5

PA Type Electric Hoist With Remote Control photo-6

US$ 39.00 - 42.00 MOQ: 100 Boxes

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Hebei, China

Brand Name:

Yunxiang

Contact Supplier Request Quote Chat Now

Hebei Jiuniu Hoisting Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Hebei, China

Brand Name Yunxiang

Model Number PA100-1000KG

Usage Mining Hoist

Power Source Electric

Sling Type Wire Rope

Maximum Lifting Weight 1000kg

Maximum Lifting Height 30m

Lift Speed 8m/min

Certification ISO9001:2008

Warranty 12 Months

After-sales Service Provided Overseas third-party support available

Product Description

Electric Power Source and Wire Rope Sling Type mini electric hoist 100kg

It has emergency stop switch and forced open limit switch. The protection class is IP54, and has thermal protection device.

Min-Electric hoist Technical Parameters:

Specification	Method of use	Rated volt(V)	Input power(w)	Rated lifting weight(kg)	Lifting speed (m/min)	Lifting height (m)	Quantity/CTN (PCS)	Packing dimension (cm)	G.W/N.W(kg)
PA200	Single-hook	220/230	510	100	10	12	2	473716	24/22
	Double-hook			200	5	6
PA250	Single-hook	220/230	510	125	10	12	2	473716	25/23
	Double-hook			250	5	6
PA300	Single-hook	220/230	600	150	10	12	2	473716	26/24
	Double-hook			300	5	6
PA400	Single-hook	220/230	980	200	10	12	2	524517.5	35/33
	Double-hook			400	5	6
PA500	Single-hook	220/230	1020	250	10	12	2	524517.5	36/34
	Double-hook			500	5	6
PA600	Single-hook	220/230	1200	300	10	12	2	534519	41/38
	Double-hook			600	5	6

Electric hoist
with pulley reeving system. Single phase electric motor,
230 V~50 Hz. Protection class: IP 44. Pressurized cast aluminium alloy casing. Plastic ventilator cover.
Twisted steel wire cable with rubber stop and mounted spring hook. Cable pull-in speed: 10 m/min (simple) - 5 m/min
(double); for 1600W, 8 m/min (simple) - 4 m/min (double).
Delivered with a spring hook on bearings (to double load capacity) and an attachment system for tubes or a hoist frame (2 pads + bolts).

- 480 W - 100 kg : 18 m - 200 kg : 12 m
- 540 W - 125 kg : 18 m - 250 kg : 12m
- 950 W - 200 kg : 18 m - 400 kg : 12 m
- 1020 W - 250 kg : 18 m - 500 kg : 12m
- 1200 W - 300 kg : 18 m - 600 kg : 12m
- 1600 W - 495 kg : 12 m - 990 kg : 12m

Company Information

Hebei Jiuniu Hoist Machinery Manufacturing CO.,LTD is an electric hoist, mini electric hoist , CD1 electric hoist , chain electric hoist , two -phase hoist, electric cars, mini electric hoist frame, pallet truck, hydraulic jack, screw jack and other professional production and processing company , has a complete , scientific quality management system. Hebei Jiuniu Hoist Machinery Manufacturing CO.,LTD integrity , strength and quality of products recognized by the industry . Welcome friends to visit, advising and business negotiation.

Packaging & Shipping

FAQ

1. If you want inquiry, please provide us this information:

which product,which size, quantity,port,and with tax or not.

2. About sample?

The buyer should offer the cost and freight, if the quantity is big then can turn back all of it after placing the order.

3. About payment?

L/C or 100% TT as deposite, if amount more than 5000usd or 30%TT as deposite, balance after B / L copy.
4. How long does it take to receive my order?

About 25 Days from we get the down payment, 10 days for sample order or as per your requirement.

5. The Mini Order?

We can accept one piece order.

If you have any question please contact with us without heistation, your positive comment will be highly appreciated.Thanks for your visiting and looking forward to sincere cooperation with you.
