Automatic Vertical Glass Washing Machine
US$ 10,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Glass Washing and Drying Machine
Production Capacity:
2-7m/min
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vertical Glass Washer and Dryer MachineNegotiableMOQ: 1 Set -
China Manufacturer Vertical Glass Washing MachineNegotiableMOQ: 1 Set
-
Automatic Washing Machine for Glass ProcessingNegotiableMOQ: 1 Set
-
Global Supplier Vertical Glass Washing MachineNegotiableMOQ: 1 Set
-
High Efficient Glass Washing MachineNegotiableMOQ: 1 Set
Condition
New
Machine Type
Glass Washing and Drying Machine
Production Capacity
2-7m/min
Place of Origin
Beijing, China
Brand Name
SAGERTEC
Model Number
SZ-VW16
Voltage
customized
Power(W)
24kw
Dimension(L*W*H)
6000*1500*2400mm
Weight
3500kg
Certification
CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
SZ-VW16 Glass Washing Machine
1)The transmission is applied with gear system,frequency for speed adjustment,the brushes are driven by 2 groups of motors independently,so that ensure the stability.
2)Equipped with 3 pair of brushes,available for LOW-E glass,coated glass and mirrors.
3)2 pair of special air knife with warm air for drying system.
4)All the parts connected to the water are stainless steel or waterproof material made.
| model | min size | max width | thickness | speed | power | weight | dimension |
| w33 | 500*500mm | 3300mm | 3-25mm | 0-7m/min | 35kw | 4800kg | 5500*4500*2840mm |
| w30 | 500*500mm | 3000mm | 3-25mm | 0-7m/min | 35kw | 4300kg | 5500*4200*2840mm |
| w25 | 400*400mm | 2500mm | 3-25mm | 0-12m/mi | 35kw | 3800kg | 5500*3600*2840mm |
| w20 | 400*400mm | 2000mm | 3-25mm | 0-12m/mi | 28kw | 3200kg | 5500*3100*2840mm |
| vw16 | 500*500mm | 1600mm | 3-19mm | 2-7m/min | 24kw | 3500kg | 6000*1500*2400mm |
| sw08 | 150*150mm | 800mm | 3-19mm | 0.7-3.5m | 10kw | 1200kg | 280081350*1000mm |
| sw12 | 150*150mm | 1200mm | 3-19mm | 0.7-3.5m | 12kw | 900kg | 3500*1750*1000mm |
| sw16 | 200*200mm | 1600mm | 3-19mm | 0.7-3.5m | 13kw | 800kg | 4000*2150*1000mm |
