Laminated Glass Grinding Machine
- 15 Set / Sets per Month
- Tianjin Port
- T/T
Product Details
Condition: | New | Machine Type: | Glass Edging Machine | Production Capacity: | 0.8-5.5m/min |
Place of Origin: | Beijing, China | Brand Name: | SAGERTEC | Model Number: | SZ-DJB10 |
Voltage: | Requirements | Power(W): | 23.1kw | Dimension(L*W*H): | 7800*1000*2500mm |
Weight: | 3500kg, 3500kg | Certification: | CE | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Laminated Glass Grinding Machine
Model | Min.Size | Thickness | Speed | Power | Bevel Angle | Spindles | Weight | Dimension |
SZ-DJB9 | 80*80mm | 3-25mm | 0.8-5.5m/min | 21.3kw | 0-45 | 9 | 3500kg | 7800*1000*2500mm |
SZ-DJB10 | 80*80mm | 3-25mm | 0.8-5.5m/min | 22KW | 0-45 | 10 | 3800kg | 7900*1000*2500 |
SZ-DJB11 | 80*80mm | 3-25mm | 0.8-5.5m/min | 24.3kw | 0-45 | 11 | 4200kg | 7920*1000*2500mm |
1.professional for flat edging with 45 degree arrissing and miter edging from 0-45.
2.The input & output adopt Synchronous rise/lower, to make grinding-volume adjustment easy&convenient.
3.Pneumatic polish at promotion, the processed edges as shinny as glass surface.
4.PLC control, all the parameter are set by touch screen.
5.Variable frequency motor for driving, the speed can be adjusted on touch screen directly.
6.Schneider electronic, stainless steel water tank, independent polishing tank with automatic stirrer for cerium.
7.The machine base, beams and base of spindle are made of excellent cast iron, all the cast and steel parts are
treated by tempering, ensure the best performance and stability of machines in different area of all over the world.
Established in 2008, Sager Tech.is a professional designer and manufacturer for machinery, which is specialized in
glass industry. We are located in Beijing, with convenient transportation access. All of our machine comply with
CE regulation and are greatly appreciated in a variety of different markets all over the world.
At initially, Sager was devoted to design and produce glass laminating equipment as long as provide the soluti--on
to work for laminating glass. With a fast development, Sager was starting up the project for new glass
processing machine by optimized cooperation and source integration. Now, our products range is increased,
which include completed PVB--EVA laminating production line, laminating furnace and material, all the type of
grinding machine, washing machine, drilling machine as well as sandblasting machine.
As a result of our high quality products and outstanding customer service, we have gained a global sales
network reaching USA, Europe, Australia, South America etc.
Our business philosophy is TECHNOLOGY RENOVATION, COST CONTAINMENT, QUALITY CONTROL
and SATISFACTORY AFTER-SALE SERVICE. Being provide qualified and advanced products for our clients
in glass industry is our mission.
If you are interested in any of our products or would like to discuss a custom order. Please feel free to contact us.
We are looking forward to forming successful business relationships with clients around the world in the near future.
If you want to know more about our glass machines, please contact.
