1. Description:
snack equipment adopts advanced extruding technique which can extrude two kinds of products
with different textures and tastes out of doublescrew extruder at the same time. This line uses advanced
extruding technology, through changing moulds and production technics to produce many kinds of popular
snack food in the market, such as rolls, crispy stick, fragrant chicken, etc.
2. Raw materials: adopts corn, rice, wheat, oat, barley etc as ingredients
3. Products: Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart
shape by adjusting the mould in the extruder
4. Capacity: 150kg/h, 240kg/h, 500kg/h
2. Raw materials:
adopts corn, rice, wheat, oat, barley etc as ingredients
3. Products:
Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower
and heart shape by adjusting the mould in the extruder
4. Capacity:
150kg/h, 240kg/h, 500kg/h
5. Flow chart:
Mixing system---Extrusion system---- -Drying system----Flavoring system---Packing system
6. Voltage in China:
Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according
to customers’ Local voltage according to different countries
7. Machines Materials:
All the machines are made by stainless steel
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
MT-65 |
81.5kw |
53kw |
100-150kg/h |
21000x1200x2200mm |
MT-70 |
115kw |
76kw |
200-240kg/h |
23000x1500x2200mm |
MT-85 |
181kw |
117kw |
400-500kg/h |
28000x3500x4300mm |
1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel
and screw, when roasting or replacing of materials.
2. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.
3. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.
4. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
5.The gearbox has automatic lubrication function, with extends gear life.
6. Main Motor from SIEMENS(CHINA), ensure its Powerful Extrusion and Excellent Performance.
9.Quick Details
Condition: New
Place of Origin: Shandong, China (Mainland)
Brand Name: MT
Model Number: MT65/MT70/MT85
Application: snack food / nutrition food/food
Power(W):30-150 kw
Dimension(L*W*H): 21000x1200x2200mm
Certification: CE/ISO9001
After-sales Service Provided: Engineers available to service machinery overseas
Packaging & Delivery
Packaging Details: Suitable for export wooden box
Delivery Detail: About 35 days after receiving the down payment
Our company(MT Machinery Co., Ltd.'s )has good experience of the industry development. We have well-experienced managers, outstanding engineers as well as well-trained technical workers. By constant
technical exchange with well-known firms of the same line in the world and also by introduction
of advanced technique and experience into our company, we have established a strong technical guarantee system. Our company is a manufacturer of puffed extruder and food machinery.
Our products are sold very well throughout China and are also introduced to Southeast Asia, East Europe, Africa and other regions. Our market share is increasing each year.
Installation and after-sale service system:
1.Installation and commissioning
2.Project planning and design services
3.Training of equipment maintenance and operating personally
4.New production techniques and formulas
5.1 year complete warrantee
I. What Is Double Screw Extruder
Double Screw Extruder can use corn flour, wheat flour, rice flour, soya bean meal, peanut meal etc to produce
inflated snacks and non-inflated pellets products by changing screws.
It consists of feeding system, extruding system, cutting system, heating system, driving system, lubricating
system, water-cooling system and controlling system.
II. Why You Must Choose Us
1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of
materials.
2. It adopts speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin
screw feeding machine guarantees stable materials feeding in the whole food process.
3. The gearbox has automatic lubrication function, with extends gear life.
4. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.
5. Barrel with water-cooled circulation, it makes extruder can be used not only for corn/rice,
also for wheat flour/starch which are raw materials with high viscosity. Through different moisture-extrusion temperature ratio, it can make whole-expanded and half expanded as different
type of products.
6. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
