corn snacks food machinery
corn snacks food machinery /snacks food machinery /snack food processing line/ corn snacks food processing line
we packing use wooden box ,when sign the contract ,after we get the deposite 40days shipping the container .
after shipping ,our engineer will going to customer factory installation and teaching .
we Jinan MT machinery&equipment CO.,LTD is professional do the snacks food machinery and pet food machinery ,we have good engineer have many years installation experience and technology ,will help you do the good quality food .
machine material :we use stianless steel material 304.
Puffed Extruded Corn Snack Food Making Machine
Snack Food Making Machine,
Corn Snack Food Machine,
Co-extruded Snack Food Machine
I. What Is Double Screw Extruder
Double Screw Extruder can use corn flour, wheat flour, rice flour, soya bean meal, peanut meal etc to produce inflated snacks and non-inflated pellets products by changing screws.
It consists of feeding system, extruding system, cutting system, heating system, driving system, lubricating system, water-cooling system and controlling system.
II. Why You Must Choose Us
1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
2. It adopts speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine guarantees stable materials feeding in the whole food process.
3. The gearbox has automatic lubrication function, with extends gear life.
4. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.
5. Barrel with water-cooled circulation, it makes extruder can be used not only for corn/rice, also for wheat flour/starch which are raw materials with high viscosity. Through different moisture-extrusion temperature ratio, it can make whole-expanded and half expanded as different type of products.
6. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
III. Technical Parameters
1. Description:
Twin screw extruder adopts corn, rice, wheat, oat, barley etc as ingredients to make puffs snack. Through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter. The product shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.
2. Raw materials: adopts corn, rice, wheat, oat, barley etc as ingredients
3. Products: Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder
4. Capacity: 150kg/h, 240kg/h, 500kg/h
5. Flow chart: Mixing system---Extrusion system---- -Drying system----Flavoring system---Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel
8. Technical Parameters
Model |
Installed power |
Real power |
Output |
Dimension |
MT-65 |
81.5kw |
53kw |
100-150kg/h |
21000x1200x2200mm |
MT-70 |
115kw |
76kw |
200-240kg/h |
23000x1500x2200mm |
MT-85 |
181kw |
117kw |
400-500kg/h |
28000x3500x4300mm |
9. Why you choose us
