Industrial Glass Stright Line Beveling Machine Glass Polishing Machine
- 15 Set / Sets per Month
- Tianjin Port
- T/T
Product Details
Condition: | New | Machine Type: | Glass Beveling Machine | Production Capacity: | 0.5-5m/min |
Place of Origin: | Beijing, China | Brand Name: | SAGERTEC | Model Number: | SZ-XB351 |
Voltage: | 380V 50HZ(optional ) | Power(W): | 22kw | Dimension(L*W*H): | 6500*1300*2500mm |
Weight: | 1500kg | Certification: | CE | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Industrial Glass Stright Line Beveling Machine Glass Polishing Machine
Mini Size: 100*100mm
Max Size: 2500*2500mm
Glass Thickness: 3-19mm
Max. Width of bevel: 40mm
Processing Speed: 0.5-5m/min
Bevel Angle:0-25°
Installed Power: 22KW
No.of Spindle: 9 PCS
Weight: 4000kg
Dimension: 6500*1300*2500mm
Model | Min.Size | Thickness | Angle | Max.Bevel | Speed | Power | Spindle | Dimension |
SZ-XB351 | 100*100mm | 3-19mm | 0-25 | 40 | 0.5-5m/min | 22kw | 9 | 6500*1300*2500mm |
SZ-XB361 | 100*100mm | 3-19mm | 0-25 | 40 | 0.5-5m/min | 24kw | 10 | 6700*1300*2500mm |
SZ-XB361A | 25*25mm | 3-19mm | 0-45 | 45 | 0.6-6m/min | 25kw | 10 | 7000*1300*2500mm |
SZ-XB371 | 100*100mm | 3-19mm | 0-25 | 45 | 0.6-6m/min | 26kw | 11 | 7200*1300*2500mm |
SZ-XB371A | 25*25mm | 3-19mm | 0-45 | 50 | 0.6-6m/min | 28kw | 11 | 7200*1300*2500mm |
1.This machine is professional for beveling various mirror and glass with polishing on the side edge,
the mini.glass size can be 100*100mm.
2.Input and output transmission adopt timing belts, which improve the stability of transmission.
3.To make grinding-volume adjustment easy and convenient, the input and output adopt Synchronous rise
and lower system.
4.All the parameters are set by touch screen and this machine is equipped with PLC control.
5.Transmission speed can be adjusted on touch screen directly and the variable frequency motor for polishing.
6.ABB Spindles, Schneider electronic, stainless steel water tank and independent polish tank with automatic stirrer for cerium.
7.The machine base, beams and base of spindle are made of excellent cast iron. All the cast and steel parts
are treated by tempering to ensure the best performance and stability of machines in different ares of all over the world.
Established in 2008, Sager Tech.is a professional designer and manufacturer for machinery, which is specialized
in glass industry. We are located in Beijing, with convenient transportation access. All of our machine comply with
CE regulation and are greatly appreciated in a variety of different markets all over the world.
At initially, Sager was devoted to design and produce glass laminating equipment as long as provide the solution
to work for laminating glass. With a fast development, Sager was starting up the project for new glass processing
machine by optimized cooperation and source integration. Now, our products range is increased, which include
completed PVB-EVA laminating production line, laminating furnace and material, all the type of grinding machine,
washing machine, drilling machine as well as sandblasting machine.
As a result of our high quality products and outstanding customer service, we have gained a global sales network
reaching USA, Europe, Australia, South America etc.
Our business philosophy is TECHNOLOGY RENOVATION, COST CONTAINMENT, QUALITY CONTROL and
SATISFACTORY AFTER-SALE SERVICE. Being provide qualified and advanced products for our clients in glass
industry is our mission.
If you are interested in any of our products or would like to discuss a custom order. Please feel free to contact us.
We are looking forward to forming successful business relationships with clients around the world in the near future.
