Home > Products > Plastic extrusion production line > PVC Plastic water supply pipe extruder
PVC Plastic water supply pipe extruder
- 100 Set / Sets per Month
- SHANGHAI PORT
- T/T
Product Details
| Condition: | New | Application: | Pipe | Plastic Processed: | PVC |
| Screw Design: | Other, Conical twin screw | Automatic Grade: | Automatic | Place of Origin: | Jiangsu, China |
| Brand Name: | WUHE-PVC Plastic water supply pipe extruder | Model Number: | SJSZ | Voltage: | 220V/380V/415V440V |
| Power(W): | 70-300KW | Dimension(L*W*H): | 35M*2.5M*3M | Weight: | 5000-15000KG |
| Certification: | CE, ISO9001-2000 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PVC Plastic water supply pipe extruder
Application:
PVC pipe is widely used in building water supply and drainage system, irrigation, electric conduit, air exhaust pipe and so on.
PVC Plastic double screw pipe making machine produces PVC pipe which diameter is from 16mm~630mm. It can produce pipe in different thickness by changing the type of machine and mould.
The production line is composed by Conical twin screw extruder, Pipe mould, Vacuum calibrator, Cooling tank, Printer, Haul-off machine, Cutter, Stacker, Belling machine and so on.
Features:
1. It adopts conical twin screw extruder for high extrusion pressure and good effect of plasticizing.
2. Reliable temperature control system ensures the high quality pipes.
3. Adopt PLC control for easy operation.
4. Low consumption, high output, stable running.
5. Auxiliary equipments also can be chosen: Pipe crusher, PVC milling machine, Mixer, Pulverizer etc.
Paramete of PVC Plastic water supply pipe extruder line
| Specification | GF63 | GF110 | GF160 | GF250 | GF400 | GF630 | GF800 |
| Item | Diameter 16-63 | Diameter 16-110 | Diameter 32-160 | Diameter 63-250 | Diameter 160-400 | Diameter 315-630 | Diameter 450-800 |
| Diameter of pipe(mn) | 16-63 | 16-110 | 32-160 | -250 | 160-400 | 315-630 | 450-800 |
| Claw number of haul off | 2 | 2 | 2 | 3 | 4 | 6 | 8 |
| Hauling force(KN) | 6 | 8 | 11 | 20 | 30 | 40 | 50 |
| Haul off speed(m/min) | 10 | 8 | 6 | 5 | 4 | 2 | 2 |
| Total power of down stream(KW) | 14 | 14 | 14 | 21.5 | 41 | 56 | 64 |
Extruder of PVC Plastic water supply pipe extruder
| Model | SJZ-45 | SJZ-51 | SJZ-55 | SJZ-65 | SJZ-80 | SJZ-92 |
| Screw diameterz(mm) | 45/90 | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
| Screw speed(rpm) | 45.5 | 30 | 30 | 34.7 | 36.9 | 32.9 |
| Screw length(mm) | 989 | 1100 | 1200 | 1440 | 1800 | 2500 |
| Motor power(KW) | 15 | 18.5 | 22 | 37 | 55 | 110 |
| Heating power(KW) | 12 | 16 | 18 | 24 | 36 | 86 |
| Capacity(kg/h) | 40-60 | 60-100 | 80-140 | 160-300 | 220-450 | 400-600 |
| Weight(kg) | 2800 | 3200 | 3500 | 4000 | 5000 | 10000 |
PVC Plastic water supply pipe extruder for diameter from 50-160mm
PVC Plastic water supply pipe extruder for diameter from 160-400mm
Certificate
For different range of PVC Pipe, the production line is different.
For more details, Welcome to contact us.
Contact Us
- Zhangjiagang Wuhe Machinery Co., Ltd.
- Contact nameSales Manager
- Phone86-512-58536100
- Address(Zhangjiagang Wheat And Paddy Breeding Farm) Leyu Town
