Automatic Vertical Pillow Pouch Chips Snack Packing Machine
1.The machine is suitable to use packing solid material, such as puffed food, shrimp slice, peanuts, popcorn, chocolate, seeds etc. which the shape is roll, grain, slice.
2.The packing machine consists of a tool box, two horizontal sealing heat rods, two vertical sealing heat rod, two cutters, three open spanners, a set hex key wrench, a copper brush, two screw drivers, a belt, two thermocouple and a printer accessories. The components all are from famous brand.
3.The processes of measuring, making, filling, sealing, code printing, cutting and counting etc. can be done automatically.
4.)Controlled by PLC, easy operation, the parameter setting is convenient and easy.
5.)Check weigher, metal detect machine and finished product conveyor are optional for customers.
II. Why You Must Choose Us
1. The food-touching parts are made by food grade stainless steel.
2.For PLC and PC Programmer, we adopt famous Brand Weinview and Mitsubishi respectively.
III. Technical Parameters
Model |
mt-388 |
mt-388X |
Film Width |
120-320mm |
180-380mm |
Film Thickness |
0.04-0.07mm |
0.04-0.07mm |
Film Roll Diameter |
Max.300mm |
Max.320mm |
Packaging Speed |
35-88bag/min |
35-70bag/min |
Bag-making Size |
(L)50-220mm (W) 50-150mm |
(L)60-280mm (W) 70-180mm |
Metering Range |
50-550ml |
50-750ml |
Power Specification |
220V/50HZ. 2.2KW |
220V/50HZ. 2.2KW |
Machine Dimension(L×W× H) |
970x680x1650mm |
1100x800x1800mm |
Machine Weight |
250KG |
300kg |
IV. Bags It can Pack
V. Strong Fumigation Case or 20'GP or 40'HQ
The machines is possible to pack in wooden case or nude pack after wraping by plastic film.
VI. We Provide Satisfied Service & Turnkey Solution
a.) Consultation service before, during, and after sales;
b.) Project planning and design service;
c.) Debugging of equipment until everything is functional;
d.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;
e.) Training of equipment maintenance and operating personally;
d.) New production techniques and formulas;
e.) Provide 1 year complete warranty and life-time maintenance service.
company information
MT Machinery Co., Ltd.'s products include double screw, single-screw extrusion machine, automatic continuous frying pot,snack foods, pet food production line production line,bugles crescent fish salad production line, nutrition Rice noodles, fried noodles production line production line,spiral shell production line, the dog biting rubber-production line, breakfast cereals, maize production line,tissue protein production line, regenerated rice production equipment, small instant noodles production line. With the industry's senior talent and technology advantages of the elite, and the "pragmatic, innovative, enterprising, honest" business philosophy, "serious, active, rigorous, efficient"style of doing things, to provide high-quality products to customers. Company with strong technical strength, high-quality products, reasonable price, perfect after sale-service, is willing to sincerely cooperate with you, create a better future.
We have years' experience in this field, and by now, we have established deep and friendly cooperation with many countries of the world, such as Europe, Asia, Africa etc. For many years, we keep providing reliable quality and considerate service. 2. Equipment Component of Cheap Yellow Dry Granular Bread Crumbs Processing Line Mixer, Screw conveyer, Double screw extruder, Shaping machine, Hoister, Pulverize machine, Sieve, Air conveyer, Vibrant fluid bed Also, we will provide you 4 sets of trolleys, each with 12boxes. Strong Fumigation-free Case or 20'GP or 40'HQ The machines will be packed in strong fumigation-free case or wrapped by plastic film placing in 20 or 40 feet container
