Help CenterAutomatic Garage Door Operator
Related Products
Specifications
automatic garage door operator without chain and guiding rail,more conventinet to transport and installFeatures:
1)This kind of automatic garage door operator is our patent product,solve the problem of installation if there is a crossbeam inside garage.
2)This automatic garage door operator doesnt need the rack, guide screw and slide bearing as a traditional opener does, it drives the Spring pole directly by motor. It takes small volume, convenient to transport, and save the charge of transportation.
3)Time---lapse light, storage power, infrared sensor, alarm system programmable....
4) Rebound meeting with obstacle in its down moving and stops when meeting obstacle in its up moving
5) Storage power, infrared sensor, alarm system programmable....
6) Many types of transmitters for choosing
7) The users can open and close the door by remote control operation, electric operation and manual operation
8) we could control this automatic garage door operator normally in the out side even in a bad weather condition
9) With Wire rope tensioning screw accessory, more theftproof against being pried.
10) A big Ring Transformer inside the controller to make sure it could perfectly work in a unstable voltage.
11) Use DC motor, with the safe voltage DC24
Technical parameter
Name |
Specifications |
||
Power supply |
110/220/240v±10% 50/60Hz |
||
Power dissipated in off state |
≤5W |
||
Max elevating power |
600N |
800N |
1000N |
Motor noise |
55dB |
||
Motor power |
90W |
120W |
150W |
Working speed |
0.12m/s~0.14m/s |
||
Remote control distance |
≤50m |
||
Working temperature |
-20~60 |
||
Max elevating high |
≤2.5m |
≤3.5m |
≤4.2m |
Optional garage door specification |
≤8 |
≤12 |
≤15 |
