Auto wheel vacuum coating machine
Technical parameter:
|
Mode Dimension |
JY-W 1200 |
JY-W 1400 |
JY-W 1600 |
JY-W 1800 |
1200*1400mm |
1400*1800mm |
1600*1800mm |
1800*2000mm |
Film Type |
Semitransparent film, non-conducting film, gold, silver, red, blue, green, purple, seven color, etc. |
Power source Type |
Thermal evaporation power, ion bombard power, RF power |
Vacuum chamber structure |
Vertical double/single door, horizontal single door, pump system postposition |
Ultimate vacuum |
8.0*10-4Pa |
Vacuum system |
Diffusion pump +Roots pump +Mechanical pump +Holding pump |
Pump time |
Pump from atmosphere to 5.0*10-2,6 minutes |
Workpiece motion mode |
Public rotation/Frequency control |
Control mode |
Manual/Automatic all-in-one mode, Touching screen+PLC |
Remark |
We can design the dimension of the vacuum chamber according to customer’s demand. |
We can make design the dimension of the vacuum chamber according to your requirement. We can also design and configure the vacuum unit and electric controlling system according to your requirement.
