Help CenterPhoto-Sensitive Nylon Photopolymer Printing Plate
Related Products
Specifications
Photo-Sensitive Nylon Photopolymer Printing Plate1,Green Product
2,Samples available
3,Excellent Solid print performance
Photo-Sensitive Nylon Photopolymer Printing Plate
Features:
Green Product, suitable for water base ink
Optimal hardness and flexibility
Excellent dot and isolated line reproduction
Solid printing performance
High latitude of exposure and processing
Good ink transfer
High impression.
Photopolymer Printing Plate Technical Parameters
Type |
R635 |
R550 |
R470 |
R394 |
R318 |
R284 |
R284H |
R254 |
R228L |
R170L |
R170H |
Rl14L |
Plate thickness (mm ) |
6.35 |
5.50 |
4.70 |
3.94 |
3.18 |
2.84 |
2.84 |
2.54 |
2.28 |
1.70 |
1.70 |
1.14 |
Rigidity (Shore A) |
33-35 |
35-38 |
35-38 |
41-45 |
40-38 |
45-48 |
58-62 |
55-58 |
57-60 |
60-62 |
67-72 |
72-73 |
Recommended relief depth (mm ) |
2.2-3.0 |
2.0-3.0 |
2.0-3.0 |
1.8-2.0 |
0.9-1.5 |
1.0-1.2 |
1.0-1.4 |
0.9-1.2 |
1.0-1.1 |
0.7-0.9 |
0.7-0.9 |
0.6-0.7 |
Image reproduction |
3%~95% |
3%~95% |
3%~95% |
3%~95% |
2-95% |
2%~95% |
2%~95% |
2-95% |
2%~95% |
2%~95% |
2%~95% |
2-95% |
Maximum line, line/inch |
85 |
85 |
85 |
100 |
120 |
120 |
120 |
133 |
133 |
150 |
150 |
150 |
Minimum isolated line |
0.30mm (0.0118inch) |
0.30mm (0.0118inch) |
0.30mm (0.0118inch) |
0.30mm (0.0118inch) |
0.175mm (0.0068inch) |
0.175mm (0.0068inch) |
0.175mm (0.0068inch) |
0.15mm (0.0059inch) |
0.15mm (0.0059inch) |
0.15mm (0.0059inch) |
0.10mm (0.004inch) |
0.10mm (0.004inch) |
Minimum isolated dot |
0.50mm (0.0197inch) |
0.50mm (0.0197inch) |
0.50mm (0.0197inch) |
0.50mm (0.0197inch) |
0.25mm (0.01inch) |
0.25mm (0.01inch) |
0.25mm (0.01inch) |
0.2mm (0.0079) |
0.20mm (0.0079inch) |
0.20mm (0.0079inch) |
0.20mm (0.0079inch) |
0.2mm (0.0079) |
Suitable ink |
water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25% |
water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25% |
water and alcohol-based ink, UV ink, some tested solvent inks |
water-based ink, alcohol-based ink and UV-ink |
||||||||
Main application |
Corrugated board |
Corrugated board |
Corrugated board, thick board, paper
|
Label, flexible package, carry bag, folded paper box and beverage package |
Film, label, flexible package, carry bag, folded paper box
|
Film, label, flexible package, carry bag, folded paper box and beverage package |
Film, label, flexible package, carry bag, folded paper box, beverage package, varnished plate |
|||||
Note:
1) Platemaking conditions: light of 80 watts (11.7mW/cm2 under 365nm), platesetter temperature 24-30°C.
2) In fact, the export type of R394 is R394-II, and the export type of R284 is R284-II.
3) R170L divides two systems; the former is more resistant to UV inks.
4) All the above data is depended on our plate-making device. Due to the different requirements of plate-making device, UV lamp power, relief depth and print image, the above recommended time can be changed appropriately. Customers should test on their own device for optimum plate quality.
Certificate:
Application:
Photo-Sensitive Nylon Photopolymer Printing Plate
