Super quality offset plates CTcP, uv ctp plate
The technologies of our uv ctp plate base treatment and coating formulation are all R&D by our company independently. This plate is not only suitable for UV-CTP platemaking but also suitable for conventional CTP platemaking.
UV CTP Plate Features
1. High sensitivity which could raise platemaking efficiency.
2. Exquisite grains, with excellent water-retaining property.
3. Strong stability.
4. Strong adaptability, could compatible with a broad range brands and types of platemakers, developing
machines, developers and feeding liquids.
5. Simple platemaking process, with low cost, high efficiency and low error rate.
6. Improve presswork quality.
Main Technical Specification and Processing Conditions
Type |
Positive UV-CTP plate |
Plate Base |
Electrochemical grains, anodized aluminium base |
Thickness |
0.15mm, 0.3mm |
Use |
Top grade commercial light printing and top grade commercial printing |
Sensitivity(mj/cm2) |
80~100 |
Gray Scale Ruler Clean Level |
The third level |
Resolution |
Dot reproduction 2~98%(175lpi) |
Run Length |
50000~100000 impressions |
Size |
Max length of short edge is 1480mm,cutting diagonal error≤0.5mm |
Shelf Life |
Under the temperature of 10~25°C,with a humidity not higher than 65%, shelf life is 1 year |
Certificate:
Facility:
Characteristics:
Excellent spectral property matches with UV platesetters. Platemaking speed reaches 10-15 2-up sheets/ hour with good dot reproduction. It has good developing property with broaden compatibility and higher run length up to 100,000 impressions, so it is proper for precise color printing.
The positive plate is a sort of light-decomposition plate. The photosensitive layer decomposes when exposed to light and it is removed during developing. So the non-image area is formed and unexposed region turns out to be printing image area. Generally speaking, during UV-CTP plate-making we need to remove a larger area which takes longer time to expose and plate-making is slower than the negative plate comparatively.
Professional Service:
Super quality offset plates CTcP, uv ctp plate
