"SmartManufacture" ID Card Laminator

"SmartManufacture" ID Card Laminator photo-1
"SmartManufacture" ID Card Laminator photo-2
"SmartManufacture" ID Card Laminator photo-3
"SmartManufacture" ID Card Laminator photo-4
"SmartManufacture" ID Card Laminator photo-5
"SmartManufacture" ID Card Laminator photo-6
US$ 10,655 - 13,114 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other
Packaging Material:
Plastic
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Hydraulic
Voltage 380V or 220V 50/60Hz
Power 25KW
Place of Origin Zhejiang, China
Brand Name SmartManufacture
Model Number SMCLM-3A
Dimension(L*W*H) 1750mm*1050mm*1650mm
Weight 2150KGS/2350KGS
Certification CE,ISO9000
After-sales Service Provided Engineers available to service machinery overseas

SMCLM-3A RFID Contactless Smart Card Laminating Machine

New function: installed temperature checking monitor system and pressure checking monitor system, automatic adjust temperature and pressure.

Lamination Area    usual 350*520mm or 420*520mm or any other size in your order
Lamination Opening    3 openings for heating,  3 openings for cooling
Pressure Method    oil hydraulic pressure system, 2units pressure module
Control Method    PLC and Touch Screen
Pressure Range    0-16MPa ± 0.1MPa     0-40Tons
Temperature Range    room temperature to 400 centigrade
Heating Method

   electric power (imported heating elements)

   4units temperature module

   installed proportion integration differentiation program

Cooling Method    automatic chiller inside machine ( environmental protection )
Working Efficiency    180-360pcs A3+ sheets per hour
Input Voltage    380V or 220V    50/60Hz
Power    20KW
Power consumption    2-3KW per hour
Dimension    1750mm*1050mm*1650mm
Net/Gross Weight    2150KGS/2350KGS
