Specifications
Automatic high speed laminating machine corrugated carton machine1Fully automatic
2A,B,C,E,E,Fflute options
3.high precision
Automatic high speed laminating machine corrugated carton machine:
Characteristic:
1. automatic flute laminating machine is used for paper pasting between paperboard and paperboard, paperboard and corrugated paperboard. A,B,C,E,E,F flute options. 3layer, 5layer and 7layer corrugated paperboard are also ok. It features in high precision, flat and smooth.
2. The main parts adopt products from domestic famous manufactures, its advantages of long lifetime, stability. Electric parts adopt international famous products can ensure it stability.
3. The characteristics of machine steady in performance, paste accurately, facilitated in operation, low wear, saving time and labor, easy to maintain etc.
Automatic high speed laminating machine corrugated carton machine:
Technology Parameter:
Model |
BZJ-1100S |
BZJ-1300S |
BZJ-1300L |
BZJ-1450S |
BZJ-1450L |
BZJ-1600L |
|
Max sheet size[W×L(mm)] |
1100×1100 |
1300×1100 |
1300×1300 |
1450×1100 |
1450×1300 |
1600×1450 |
|
Min sheet size[W×L(mm)] |
350×350 |
350×350 |
350×350 |
350×350 |
350×350 |
350×350 |
|
|
Base paper
|
Min weight(g/m2) |
300 |
300 |
300 |
300 |
300 |
300 |
Max weight(g/m2) |
800 |
800 |
800 |
800 |
800 |
800 |
|
Max thickness(mm) |
10 |
10 |
10 |
10 |
10 |
10 |
|
|
Surface paper
|
Min weight(g/m2) |
180 |
180 |
180 |
180 |
180 |
180 |
Max weight(g/m2) |
800 |
800 |
800 |
800 |
800 |
800 |
|
|
The errors of paper pasting between paperboard and paperboard |
±1mm |
±1mm |
±1mm |
±1mm |
±1mm |
±1mm |
|
|
The errors of paper pasting between paperboard and corrugated paperboard |
±1.5mm |
±1.5mm |
±1.5mm |
±1.5mm |
±1.5mm |
±1.5mm |
|
Total power(kw) |
12 |
12 |
12 |
12 |
12 |
12 |
|
Working speed(pcs/min) |
0-100 |
0-100 |
0-100 |
0-100 |
0-100 |
0-100 |
|
Machine length(m) |
12.5 |
12.5 |
14.8 |
12.5 |
14.8 |
15.1 |
|
Weight(kg) |
5300 |
5600 |
5900 |
5900 |
6200 |
6500 |
|
