Full-automatic Computer System Die-cutter Machine

Name: Full-automatic Computer System Die-cutter Machine
Brand: Xinglong
SKU: 104887929
Availability: InStock

US$ 2,000 - 50,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, corrugated

Packaging Type:

Cartons

Dongguang Xinglong Packaging Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, corrugated

Packaging Type Cartons

Packaging Material Paper

Automatic Grade Semi-Automatic

Driven Type Electric

Power 5.0kw

Place of Origin Hebei, China

Brand Name Xinglong

Model Number XL

Specifications

full-automatic computer system die-cutter machine
1.CE Certificate
2.15-20days to finish
3.arrange debugging

Full-automatic computer system die-cutter machine

1.details and description

PLC and single color touch screen system.
distance maintenance and parameter repair .
ejector back-kicking feeding system

1The ejector back-kicking feeding system.

2.The built-in skip(intermittent)feeding feature makes offers the capability for making large-sized cartons.

3.All the transmission gears are made from quality steel through heat treatment and grinding.

4.The application of the spline-free shaft collar ensures long term operating performance and high alignmeng precision in printing.

5.Automatic zero-setting and automatic resetting.

6.Large-sized double-piece cartons can be porduced by moving the middle die.

7.The powerful cylinder main lock for th whole machine makes the system more stable.

technology parameters:

Color group	Can equipped based on consumers require
Printing paper	A,B,C.A/B,B/C,A/B/C corrugated board (Max.clearance 13mm)
Production speed	140pieces/min
Economy speed	100 pieces/min
Max.paper size	2400x1300mm
Min.paper size	600x350mm
Max.printing size	2200x1300mm
Standard printing plate thickness	7.2mm
Max.Paste Edge Width	50mm
Slot WidthMax.depth	7mmX300mm(number of blade and slot depth may be added)
Min.slot space	Main plate position 290mm; aux.plate position 50mm
Printing roller Dia.(plus printing plate Thickness)	410mm
Anilox Roller line number
