Help CenterXLD Double Head Carton Stitching Machine
Related Products
-
2 Pieces Stitching MachineUS$ 27,000 - 32,000MOQ: 1 Piece -
Corrugated Carton Machine Automatic Folder GluerUS$ 9,600 - 20,000MOQ: 1 Set
-
Thin Slitter Scorer Machine Slitting Corrugated Cardboard MachineUS$ 8,000 - 16,500MOQ: 1 Set
-
QZD-2600 Automatic Carton Gluer MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
BFY3,5ply Corrugated Cardboard Slitter ScorerUS$ 5,000 - 10,000MOQ: 1 Set
Specifications
carton stitching machine1. Double head, two sheets joint type
2. Servo motor
3.Ormon or shineder electric components
Features:
² This machine can stitch single, double, and Irregular carton.
² Adopted electric controlling to adjust size.
² Single/, double// and strengthen nail // / / // are available, be finished one time, it can meet different requirements of different clients.
² Automatic counter ejector.
² Suit for large carton, speed stitchign and easy.
² Set the program in computer to adjust stitching pitch automatically.
² Adopt electric control to adjust size, fault instruction will appear in the LCD.
² Our product can be generally applied to the three-layer or five-layer cardboard boxes as well as the uncovered ones with bottom. As for the seven-layer boxes, the equipment needs to be customized.
² Stitching pitch(samll-big)30mm-120mm can be arbitrary regulation.
² Machine speed: 500stitches/minute.
Technology Parameters:
Model |
XLD-2400mm |
XLD-2700mm |
XLD-3000MM |
Max. sheet size(A+B)*2(mm) |
4800 |
5400 |
6000 |
|
Min. sheet size(A+B)*2(mm) |
1060 |
1060 |
1060 |
|
Max.sheet size length(mm) |
2250 |
2550 |
2850 |
Min.sheet length(mm) |
350 |
350 |
350 |
Max.sheet width(mm) |
1200 |
1350 |
1500 |
|
Min.sheet width(mm) |
180 |
180 |
180 |
|
Min.sheet height(C+D+C) (mm) |
400 |
400 |
400 |
Stitching pitch(mm) |
30-120 |
30-120 |
30-120 |
No.of stitching |
1-99 |
1-99 |
1-99 |
|
Machine speed(stitch/min) |
500 |
500 |
500 |
Power Required(HP) |
10.5 |
10.5 |
10.5 |
Machine Length(mm) |
6000 |
6000 |
6000 |
ong Machine width(mm) |
3550 |
3850 |
4150 |
Machine Weight(kg) |
4000 |
1200 |
1200 |
Max.stopper Measurement |
600mm(C) |
||
Max.TS width |
45mm(E) |
||
Min.Frist stitch Pitch |
25mm(D) Uncover |
||
