2 pieces stitching machine
Use and Characteristic:
1. Double servo drive, precision accurate, mechanical transmission part decreases, can effectively reduce the mechanical trouble.
2. General in large carton, outfit was quickly and effort
3. The machine adopts computer screen shows fault and description.
4. Use horsepower: 18 HP (Japan AnChuan servo motor).
5. Tailgate electric function. Stepping motor drive precise size, transform size easily and quickly
6. To deliver the paper roller clearance electric adjustment
7. Touch screen operation, parameters (nail distance, nail number, from the number of nails, tailgate). Transform convenient and quick
8. It can nail single nail, double nail, Strengthen nail completed in one-time, can be suitable for
different kinds of customer requirements of nails.
9. Transform size just two to three minutes
10. Paper feeding section can automatic count, send after the bundle into the bundle.
11. Can nail has a top box and no cover box (the first was the shortest distance to the cartons
for 25 mm)
12. After playing with nail line, automatic alarm device. (avoid for nail the leakage nails, produce line of nail less bad product)
13. Semi-finished products nailing to the finished products display only need two operators. This can operate simply and reduce wages.
14. The workbench is in hydraulic platform (optional)
Technology parameter:
Model |
XLD-2400mm |
XLD-2700mm |
XLD-3000MM |
Max. sheet size(A+B)*2(mm) |
4600 |
5200 |
5800 |
Min. sheet size(A+B)*2(mm) |
1060 |
1060 |
1060 |
Max.sheet size length(mm) |
2250 |
2550 |
2850 |
Min.sheet length(mm) |
350 |
350 |
350 |
Max.sheet width(mm) |
1200 |
1350 |
1500 |
Min.sheet width(mm) |
180 |
180 |
180 |
Min.sheet height(C+D+C) (mm) |
400 |
400 |
400 |
Stitching pitch(mm) |
30-120 |
30-120 |
30-120 |
No.of stitching |
1-99 |
1-99 |
1-99 |
Machine speed(stitch/min) |
500 |
500 |
500 |
Power Required(HP) |
18 |
18 |
18 |
Machine Length(mm) |
6000 |
6000 |
6000 |
Machine width(mm) |
3550 |
3850 |
4150 |
Machine Weight(kg) |
4000 |
4100 |
4200 |
Max.stopper Measurement |
600mm(C) |
||
Max.TS width |
45mm(E) |
||
Min.First stitch Pitch |
25mm(D) Uncover |
||
