High speed portable XY-3 trailer mount hydraulic drilling rig for sale
Product Features
1.XY-3 drilling rig adopts CG140 model auto tranmission,has 10 rotation speeds and reasonable speed range,with eight forward rotation gears and two reverse rotation gears,high speed,strong stroke and wide scope of application.
2.Large engine power and two reverse rotation gears,can easily solve the drilling work accident.
3.The Operation handles are fixed together in reasonable layout to make it more convenient for workers to operate the machine.
4.Equipped with normally closed hydraulic chuck,operation is flexible and reliable
5.Spindle and hoist can be operated separately.
6.Spindle has big inner diameter,able to use big hexagonal drilling rod.
Technology Parameters
Model |
XY-3 |
Drilling depth |
600m |
Maximum open hole caliber |
300mm |
End hole caliber |
75mm |
Drill rod caliber |
60mm |
Drilling angle |
90~65° |
Drilling rig weight (without power) |
1600kg |
Unity machine dimensions |
2.5*0.9*1.8m |
Spindle | |
Spindle speed |
Forward 30-1050 r/min |
Reverse 29-137r/min | |
Spindle stroke |
600mm |
Spindle iinner diameter |
96mm |
Lifting capacity |
6000kg |
Hoist | |
Max. Lifting capacity with single rope |
4000kg |
Lifting speed with single rope |
0.5-1.9m/s |
Wirerope caliber |
12.5mm |
Wirerope cubic measure |
50mm |
Reel diameter |
300mm |
Hug folldgate belt width |
90mm |
Mud pump | |
Type |
BW-250 |
Displacement (with diesel engine/electric motor) |
250L/min |
Work pressure |
80KG/CM3 |
Water inlet pipe diameter |
75mm |
Water outlet pipe diameter |
50mm |
Power |
|
Diesle engine |
4105 76HP |
Electric motor |
Y180L-4 59KW |
