wheat straw fuel biomass briquette machine
- 1000 Set / Sets per Month
- Qingdao
- T/T Credit Card
- Cheap Charcoal Briquette Machine(86-15978436639)
- Wholesale Price Charcoal Briquette Machine(86-15978436639)
- Ball Charcoal Briquette Machine(86-15978436639)
- Charcoal Briquette Making Plant(86-15978436639)
- Small Scale Charcoal Briquette Machine(0086-15978436639)
- Charcoal Briquette Machine Small(0086-15978436639)
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | MY |
Model Number: | JGJ | Voltage: | 380v | Power(W): | 18.5kw |
Weight: | 2T | Dimension(L*W*H): | 1X2X3 | Certification: | ISO9001 CE |
Product Description
Specifications
Warranty for 10 years energy recycleECO- friendly,
Low investment,high benefit
Easy to operate maintain
Reasonable price
♦ Advanced belt-driving system with double motors on this biomass pellet machine, stable and reliable.
♦ Adopting high-qualified components on this biomass pellet machine, with stable performance, long service life and low noise.
♦ Whole transmission parts (including motor) of this biomass pellet machine chooses high-quality NSK/SKF bearings to ensure the transmission efficient, stable, low noise. Main motor choose Siemens.
♦ This biomass pellet machine is equipped with full single layer stainless steel conditioner, ring die and cutter.
♦ Adopting international advanced technology on biomass pellet machine: German gun drill and vacuum furnace heat manufacturing process in ring die making to ensure the pellets smooth and of high quality.
♦ A variety of overload protection devices and warning signs on biomass pellet machine.
♦ Structural alloy steel main shaft with good strength and toughness.
This biomass pellet machine is able to be widely used in pelletizing wood, sawdust, crop straw (rice straw, wheat straw, corn stalks, sorghum stalk, soybean stalk, cotton stalk, grape straw, peanut seedlings, and sunflower stalk), rice husk, grass, shrubs, branches, wood cut-off head, bamboo debris, bagasse and the like.
1. Working Principle:
Briquetting is a process that biomass is compressed under high pressure and high temperature.
The lignin content that occurs naturally in biomass is liberated under high pressure and temperature. Lignin serves as the glue in the briquetting process, thus binding, compressing the biomass to form into high density briquettes.
During this process, no binder needs to be used. So the output briquette is a type of clean and green fuel that is ideal for use in furnaces, boilers and open fires. The density of the briquettes is 0.8~1.3 g/cm3
2. Applied material:
1.wood waste, scobs, branch, palm tree;
2.bean straw, wheat straw, corn straw, cotton straw, rice straw,rice husk
tton shell, peanut shell, rice shell, palm tree, coconut shell;
4. Any plants grow in the ground.
3.Application of the biomass fuel:
1. Home heating stoves
2. Hot water boilers and the industrial boilers,
3. Biomass power plants
4. Kitchen cooking
5. Greenhouse
6. Barbecue and so on
Model | JGJ1000 | JGJ-1500 | JGJ-2000 |
Motor power(kw) | 15 | 18.5 | 22 |
Capacity(kg/h) | 700-900 | 1000-1500 | 1800-2000 |
Size and shape
| 32X32Cubic strip | 32 circle | 33 circle |
Density (g/cm3) | 0.8-1.4 | 0.8-1.4 | 0.8-1.4 |
Moisture(%) | 10-25 | 10-30 | 10-30 |
length(mm) | 3-50 | 3-60 | 3-60 |
Overall size(mm) | 1700x800x1400 | 1800x900x1660 | 1800x900x1680 |
Overall weight(ton/set) | 0.8 | 1.3 | 1.5 |
