Specifications
1.Preformed dead end clamps
2.Professional manufacture
3.factory direct price
4.ISO90012008
5.Timely delivery
Preformed dead end / preformed guy grip
|
GUY-GRIP Dead-ends, installed at the top, the breaker and the anchor, provide today’s most effective method for securing guy strand. This unique, one-piece dead-end is neat in appearance and free from bolts or high-stress holding devices. The GUY-GRIP Dead-end was the first to offer the cabled loop, a feature that provides more durabil- ity, easier tensioning and adaptability to multiple guying.
GUY-GRIP Dead-ends are made of the same material as the strand to which they are applied. They should be used on hardware that is held in a fixed position.The fitting should not be allowed to rotate or spin about the axis of the strand. They should not be used as tools including come-alongs, pulling-in grips, etc.
|
product model of the Company |
standard model of the industry | Appliceble diameter of guide wire(mm) | Applicable type of guidu wire YB/T5004-1993(mm ² ) | Reference length of wire clamp(mm) | Wrie clamp weight(KG) | Color code | Matching fittings |
| SNL-25/G | NL-25/G | 6.60 | 25 | 635 |
0.22
|
Yellow | Capel,adjustable wire,anti-theft ring clamp |
| SNL-35/G | NL-35/G | 7.8 | 35 | 711 |
0.30
|
Black | |
| SNL-50/G | NL-50/G | 9.0 | 50 | 901 |
0.53
|
Orange | |
| SNL-70/G | NL-70/G | 11.0 | 70 | 1016 |
0.82
|
Green | |
| SNL-95/G | NL-95/G | 12.5 | 95 | 1333 | 1.50 | Orange | |
| SNL-100/G | NL-100/G | 13 | 100 | 1333 | 1.50 | Yellow | |
| SNL-120/G | NL-120/G | 14 | 120 | 1460 | 2.22 | Yellow |
Accessories :
2. Rich manufacture experience.
3. Certificates: ISO9001:2008
4. High quality with competitive price.
5. Domestic and Overseas markets.
6. Well equipped with complete facilities.
7. Strict quality control and excellent after-sales service.
8. In addition to supplying varieties of types and specifications to our customers, we also accept customized product. Please contact us with your detailed drawings, our well-trained serve staff and professional engineers will get back to you according to your requirement.
9,Our company has more than 13 years of production experience
10,Our engineers have more than 10 years of experience.
11.,The packing skilled more 10 years experience.
12,Our company has a professional design team and sales team(24 hours to provide you with quality service!)
Production process:
Shanghai Shenyong Line Products Co., Ltd. is an integrative economic and technical development limited company. It specializes in design, production and sales of line electric fittings oriented products. It also provides series of services to our customers, such as installation, reconstruction, maintenance of hoisting mechanical equipment; reconstruction and maintenance of electric control equipments; production and sales of structural parts; mechanical processing and business consultation etc.
