Stainless Steel British Standard Key Switch

Stainless Steel British Standard Key Switch thumbnail-1
Stainless Steel British Standard Key Switch thumbnail-2
Stainless Steel British Standard Key Switch photo-1
Stainless Steel British Standard Key Switch photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
Pegasus, Pongee
Model Number:
PG-K286A
Contact Supplier Request Quote Chat Now
Pongee Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Keelung Taiwan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name Pegasus, Pongee
Model Number PG-K286A

Stainless Steel British Standard Key Switch



Product Description
Installation of this product can prevent the access controller failure or other unexpected accidents result in electric lock can not open the door with a key forced to switch N.O. or N.C. contacts to open the door, the product is recommended to install in the secret place to prevent the destruction of. Parallel or series in UPS (uninterruptible power system) and electric lock (Fail-safe / Fail-secured).

Specification
•Dimensions: 5(plate)/34(total depth) x 86(W) x 86(L)mm
•Hole distance: 60mm
•Material:
Face plate: stainless steel(Thickness: 1mm)
Key switch: zinc alloy
•Maximum limit power: 125VAC / 4A, 250VAC / 2A
•Contact resistance: 10Milli-Ohms Max.
•Insulation resistance: 200 Meg-Ohms Min.(500VDC)
•Dielectric strength: 1000 VAC - 1 Minute
•Operating temperature: -20℃ ~ 55℃
•Storage Temperature: <80%RH
•Life: 10,000 cycles

Dimension: Unit(mm)



Stainless Steel British Standard Key Switch

We reserve the right to change the specification without prior notice or obligation!
